The M-01S is for Balanced, Low Impedance Microphones. - High and Low Cut Filters for tone control, 4.2k Hz and 330 Hz, 6 dB/octave. - Phantom Power, +22V DC for condenser-type microphones. Active by default, cut Jumper J1 to disable. - Connector: removable terminal block.
| Performance Input | 600 tb |
|---|---|
| Input Sensitivity | -60 dBu (rated output: -20 dB), adjustable -72 to -52 dB |
| Input Impedance | 600 Ω, balanced transformer-isolated |
| Gain (Adjustable) | 32 ~ 52 dB |
| Maximum Input | -14 dB |
| Signal to Noise (S/N) | -126 dBu (EIN 200 Ohm) |
| Physical Connector | M-01F, M-01M, M-01P, M-01S |
| Power Source | 24 V DC |
| Current Consumption | 9 mA |
| Frequency Response | 25 Hz - 20 kHz ±2.0 dB |
| Distortion | 0.05 % or less (1 kHz , output: 0 dB) |
| Noise Level | -86 dB (20 Hz - 20 kHz BPF), input equivalent noise: -126 dB |
| Phantom Power | +22 V DC (active or disable selectable) |
| Tone Control | 100 Hz: 0 to -10 dB, 10 kHz: 0 to -10 dB |
| Connector | Removable terminal block (3P) |
| Dimensions (H x W x D) | 3.07'' (77.98 mm) x 1.38" (35 mm) x 3.46" (87.88 mm) |
| Weight | Max. 0.24 lb (110 g) |
