The TOA Q-N8050WP is a weather resistant door station designed to connect to an N-8000EX or N-8010EX intercom exchange. It provides high quality, hands-free conversation with a master station on an N-8000 system. The Q-N8050WP is IP54 rated with additional protection for the PCB It includes a remote controllable open collector control output (momentary 1-9 seconds). The Q-N8050WP supports the audio trigger function. Requires 3-gang back box.
Using with an electrical box or surface mounting box, the station can be mounted to a wall. The N-8050DS is in full conformity with IP44 waterproof and dust-proof standards. The operating temperature range is -10 to +50°C.
| Power Source | 48 V DC (supplied from the IP intercom exchange (option)) |
|---|---|
| Power Consumption | 1.8 W (at rated), 2.4 W (max.) |
| Wiring Method | Non-polar one pair stranded wire system |
| Transmission System | 2 wire 160 kbps echo canceller transmission system |
| Signal Level | Under 0 dB |
| Speech Method | Hands-free conversation |
| Audio Frequency Range | 300 - 7,000 Hz |
| Transmission Range | Max. 1500 m (00.65 mm. Loop resistance 170 Q) |
| Hands-free | Speaker: 3.5 cm cone-type, 1 W, 8 GMicrophone: Omni-directional electret condenser microphone |
| Contact Output | Open collector output, withstand voltage: Max. 30 V DC |
| Line Connecting Terminal | 2 wire, screw terminal (non-polar) |
| Setting Method | Flush-mount/Surface-mount |
| Operating Temperature | -10'C to +50JC |
| Operating Humidity | Under 90% RH (no condensation) |
| Housing Protection | BS EN62262: 2002: IK02 eguivalent |
| Dust/Water Protection | IP54 |
| Resistance to Environment | Passed our gas corrosion test and neutral salt spray test |
| Finish | Plate: Stainless steel (SUS304), hairlineCall button: Metal |
| Dimensions (H x W x D) | 6.4" (162 mm) x 4.5" (115 mm) x 2.1" (54 mm) |
| Weight | 1.76 lbs (0.68 kg) |
