Description

Details

TOA TS-D1100-SP PoE Monitor Speaker

The TS-D1100-SP is a dedicated speaker unit engineered for seamless integration with the TS-D1100 Series Digital Conference System from TOA Corporation. Designed for structured discussions and professional meeting spaces, this compact speaker delivers clear, intelligible conference audio to participants within an approximate 3-meter radius.

Equipped with a 1W monitor speaker, the TS-D1100-SP provides balanced sound reinforcement suitable for boardrooms, council chambers, training rooms, and corporate meeting environments. Each unit includes an individual 6-level volume control, allowing users to adjust audio levels for optimal listening comfort during discussions.

Powered via PoE (Power over Ethernet), the speaker simplifies installation by reducing the need for additional power supplies and cabling. Its streamlined design and system compatibility make it an ideal solution for basic discussion setups that require dependable, efficient audio distribution.

Features

Features

Designed for TS-D1100 Series Digital Conference Systems
Compact 1W monitor speaker for clear speech reproduction
Approximately 3-meter audio coverage radius
Individual 6-level volume control for user adjustment
PoE powered for simplified installation
Ideal for boardrooms, council chambers, and meeting rooms
Reliable audio reinforcement for structured discussions
Seamless integration with digital conference systems

Specification

Power Source	24 V DC (supplied from the TS-D1100-MU Master control unit (option), TS-D1000-SU Sub control units (option), or TS-D1000-EX Extension units (option)
Power Consumption	5W or less
Frequency Response	100 Hz - 13 kHz
Signal to Noise Ratio	60 dB or more (A-weighted)
Speaker Output	8Ω, 1W 80 dB SPL
Connection Terminal	RJ45 connector x 2
LED Indicator	Power indicator, Volume indicator
Function	Volume control function
Operating Temperature	0°C to +40°C (32°F to 104°F)
Operating Humidity	90% RH or less (no condensation)
Finish	Case: ABS resin, black
Dimensions (H x W x D)	2.18" (55.3 mm) x 8.43" (214.2 mm) x 8.32" (211.4 mm)
Weight	1.21 lbs (0.55 kg)
