TOA U-43S Unbalanced Line Input with High/Low Cut Filters and Mute-Send

By TOA Electronics

TOA U-43S Unbalanced Line Input with High/Low Cut Filters and Mute-Send

Write a Review
Part #:
U-43S
Model #:
U-43S
MSRP: $129.00
$105.00
Availability: Usually arrives in 5-9 business days. Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.
Adding to cart… The item has been added
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112
Email

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM 1-888-256-4112
Email Contact us by email or
our simple form. SEND EMAIL
The TOA U-43S Unbalanced Line Input with High/Low Cut Filters and Mute-Send is an AUX module with voice-activated muting control output, Mute send sensitivity, High and Low Cut Filters, gain control, and removable terminal block connector.

Description

The TOA U-43S Unbalanced Line Input with High/Low Cut Filters and Mute-Send is an AUX module to be used in conjunction with the 900 series and AX-1000 amplifier. It has a voice-activated muting control output. Has dual removable terminal block connector, gain control, and Mute send sensitivity. For unbalanced, line level equipment such as AM/FM tuners,tape decks and CD players. Signal at input terminals activates mute bus.

Features
  • Controls/Functions:
    • Gain Control
    • Remote Volume
  • Performance Input: 220 k ub
  • Input Sensitivity: -18 ~ +12 dBu
  • Gain (Adjustable): -30 ~ 0 dB
  • Maximum Input: +18 dB
  • Signal to Noise (S/N): 90 dBu (S/N)
  • Physical Connector: Screw Terminal

Specifications
Product Type 2-Line Input Module
Performance Input 220 ohms
Input Sensitivity 17 ~ +13 dBu
Gain (Adjustable) -30 ~ -1 dB
Signal to Noise (S/N) 55dBu
Physical Connector Removable Terminal Block
Power Source 24 V DC
Current Consumption Less than 15 mA
Input Sensitivity (Rated Output 100 mV) 100 - 3,600 mV (adjustable)
Low Cut Filter (100 Hz) -5- -15 dB
High Cut Filter (10 Hz) -7- -13 dB
Noise Output (20 Hz - 20 kHz BPF) Less than 10 V
Distortion Less than 0.05%
Frequency Response 20 Hz - 20 kHz
Signal-Activated Muting 6 - 15 mV
Input Connector 3P terminal block
Output Connector 6P card edge-connector
Dimensions (H x W x D) 3.07" (77.98 mm) x 1.38" (35 mm) x 3.64" (92.46 mm)
Weight 0.11 lb (50 g)

DOCUMENTS

Related Products

TOA U-43R Unbalanced Line Input with High/Low Cut Filters and Mute-Send

TOA U-43R Unbalanced Line Input with High/Low Cut Filters and Mute-Send

The U-43R Unbalanced Line Input with High/Low Cut Filters and Mute-Send is an AUX module to be used in conjunction with the 900 series and AX-1000 amplifier. It has a voice-activated muting control...
MSRP: $129.00
$105.00

Usually arrives in 5-9 business days.

MSRP: $129.00
$105.00
Add to Cart The item has been added
TOA U-13R Unbalanced Line Input with High Low Cut Filters and Mute-Receiver

TOA U-13R Unbalanced Line Input with High Low Cut Filters and Mute-Receiver

The U-13R is an unbalanced line input with high/low cut filters, Dual RCA connector, and gain control. It is an AUX module to be used in conjunction with the 900 series or AX-1000 amplifier. It has...
MSRP: $125.00
$102.00

Usually arrives in 5-9 business days.

MSRP: $125.00
$102.00
Add to Cart The item has been added
TOA U-03R Unbalanced Line Input with High Low Cut Filters
