The WTU-M9800 tuner may be used in any TOA mixer that accepts a 900 series module. Each module is a diversity UHF receiver with 16 user selectable frequencies. Up to two modules may be used in a frame without the use of an external power supply. A wide range of M band transmitters is available, as all 5000 series microphones and belt packs are compatible with WTU-M9800. Two whip antennas on standard BNC connectors are included. Phantom power on the antenna inputs supports the use of TOA's YW-4500 Q powered remote antennas.
| Power Requirement | Internal power supply mode : 24 V DC External power supply mode : 12 – 24 V DC |
|---|---|
| Current Consumption | 100 mA |
| Receiving Frequency | UHF, 506 – 538 MHz |
| Receiving Sensitivity | Better than 80 dB, S/N ratio (20 dBμV input, 40 kHz deviation) |
| Channel | 16 channels selectable |
| Audio Output | +6 dB (maximum deviation, 10 kΩ load) |
| Frequency Response | 100 – 12000 Hz, ±3 dB |
| Finish | Case : Steel, tin plated |
| Dimensions (H x W x D) | 3.07" (78 mm) x 1.38" (35 mm) x 3.57" (90.8 mm) |
| Weight | 0.21 lbs (0.10 kg) |
