The ZM-9002 is a remote control switch/volume panel used with the 9000 Series amplifiers. It adds 4 control inputs and 1 volume control and can be mounted in a 1-gang electrical box. One shielded conductor to chassis remote volume terminals wiring. 100 ohms (3000 ft. 22AWG) maximum loop resistance.
| Product Type | Remote Panel |
|---|---|
| Applicable Cable | Shielded cables |
| Line Resistance | Under 100Ω (loop) |
| Terminal | M3 screw terminal, distance between barriers: 7.62 mm |
| Operating Temperature | -10 to +40°C |
| Finish | Surface-treated steel plate, white, paint |
| Dimensions | 5" (127 mm) x 2.83" (72 mm) x 2.27" (56 mm) |
| Weight | 0.7 lbs |
