Xantech AC1 Controlled AC Outlet (Discontinued)

Name: Xantech AC1 Controlled AC Outlet (Discontinued)
Brand: Xantech
SKU: XANTECH-AC1
Price: 130.99 USD
Availability: OutOfStock

Write a Review

Part #:

AC1

Model #:

AC1

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Xantech AC1 is a control voltage switched outlet. It can be used for AC power management with the control output of any low voltage DC source (5-30VDC).

Description

The AC1 is a control voltage switched outlet. It can be used for AC power management with the control output of any low voltage DC source (5-30VDC).

Features

Used for AC power management
Control output of any low voltage DC source

Specifications

Maximum Switching Current	15 Amps continuous, 30 Amps peak inrush, at 120 VAC, 60 Hz
AC Circuit Breaker	Opens if AC current exceeds 15 Amps. Push-to-Reset button
AC Power Cord	120 VAC 16 gauge 5 ft., 3-conductor
Standby AC Line Current	< 2 mA (< .24 Watts)
Control Input	Plug-in screw-type terminals for two-conductor connections. Handles wire sizes from 24 to 12 gauge
Control Input Turn-ON Voltage Range	5 to 30 Volts DC, @1.5 mA/V
Control Input Turn-OFF Voltage
Dimensions (H x W x D)	2.625" (67 mm) x 2.5" (64 mm) x 4.938" (125 mm)
