Yamaha DA824 8-Channel D/A Converter (Discontinued)

Name: Yamaha DA824 8-Channel D/A Converter (Discontinued)
Brand: Yamaha
SKU: YAMAHA-DA824
Price: 1479 USD
Availability: OutOfStock

Write a Review

Part #:

DA824

Model #:

DA824

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Yamaha DA824 is a high-performance 8-channel digital-to-analog converter that can operate in conjunction with other digital audio equipment or as a stand-alone converter.

Description

The DA824 is a high-performance 8-channel digital-to-analog converter with 24-bit linear digital-to-analog converters and 128-times oversampling providing a typical dynamic range of 110 dB. Optional mini YGDAI (Yamaha General Digital Audio Interface) cards offer a variety of digital input interfaces, with support for all the popular digital audio interconnect formats, including AES/EBU, ADAT and Tascam TDIF-1.

Features

High quality 24-bit digital-to-analog converters
Balanced XLR and 1/4" phone jack output connectors
Maximum +4, +15, +18, or +24 dBm output level individually selectable for each channel
Expansion slot supports optional mini-YGDAI cards for AES/EBU, ADAT and TASCAM digital format
Word clock input and thru connectors
Signal, nominal, and peak LED indicators

Specifications

Connection	OUTPUT 1–8
GAIN SW	+24 dB, +18 dB, +15 dB, +4 dBV
Actual Source Impedance	150 Ω lines
For Use with Nominal	600 Ω lines
Nominal Output Level	+10 dB (2.45 V) +4 dB (1.23 V) +1 dB (0.87 V) –10 dBV (0.316 V)
Output Level Max. Before Clip	+24 dB (12.28 V) +18 dB (6.16 V) +15 dB (4.36 V) +4 dBV (1.58 V)
Connector	XLR-3-32 type (balanced) & TRS phone jack (balanced)
Connection	COM, WORD CLOCK IN, WORD CLOCK THRU, SLOT
Format	Mini YGDAI
Level/Impedance	RS232CTTL, 75Ω (ON/OFF) TTL, 75Ω
Connector	9-pin D-sub (male) BNC, BNC
Sampling Rate (MY8-AE, MY8-TD, MY8-AT)	39.69–50.88 kHz, 41.013–50.88 kHz
DA Conversion Resolution	24-bit linear, 128-times over sampling
Frequency Response	–3, +1 dB, 20 Hz–20 kHz
Dynamic Range	110 dB (typical)
Gain Error	±1 dB @ 1 kHz
THD	0.05%, 20 Hz–20 kHz0.01% full scale output @ 1 kHz
Hum & Noise Level	–92 dBu (typical)
Crosstalk	–70 dB between adjacent channels @ 1 kHz
Signal Delay	0.57 ms (digital input to analog output, fs = 48 kHz)
Indicators (PEAK, NOMINAL, SIGNAL, LOCK, POWER)	3 dB below full scale, 14 dB below full scale, 34 dB below full scale, Word clock lock, Power on/off
Power Requirements	120 V AC, 60 Hz
Power Consumption	40 W
Free-Air Operating Temperature	10° C to 35° C (50° F to 95° F)
Storage Temperature	–20° C to 60° C (–4° F to 140° F)
Power Cord Length	1.9 m
Dimensions (H x W x D)	3.81" (97.5 mm) x 18.88" (480 mm) x 14.44" (366.8 mm)
Weight	16.53 lbs (7.5 kg)
