The Yamaha DXR15 mk3 15" 2-Way 2000W bi-amped powered loudspeaker delivers powerful low-end, 134 dB SPL output, and advanced DSP control. Ideal for FOH, DJs, and live sound, it features Bluetooth streaming, remote control, and precision tuning for professional performance.

Description

Yamaha DXR15 mk3 15-Inch 2-Way Powered PA Loudspeaker

The DXR15 mk3 is a high-performance 2-way, bi-amped powered loudspeaker designed to deliver the deepest low-frequency response in the DXR series, along with exceptional clarity and precision. With a powerful 2000W Class-D amplifier and a maximum SPL of 134 dB, it is ideal for front-of-house applications, DJ events, and live performances that demand strong, impactful bass and consistent coverage.

Engineered with a 15-inch low-frequency driver and a 1.75-inch high-frequency compression driver, the DXR15 mk3 ensures balanced, full-range sound. Advanced technologies such as FIR-X tuning and Drive Motion Calibration optimize phase response and low-frequency accuracy, while the large-diameter horn enhances directivity across a wide frequency range. Its rugged yet lightweight injection-molded enclosure is built for durability and easy transport.

The DXR15 mk3 also features powerful DSP functionality, including FOH and monitor modes with automatic configuration via Auto V/H Position. Users can control settings remotely through the D-Remote app on iOS or Android devices, and Bluetooth audio streaming adds modern flexibility. Additional features like an intelligent feedback suppressor, dual-angle pole mounting, and optional mounting and protection accessories make it a versatile and reliable solution for professional audio environments.

Features

  • 2000W Class-D bi-amped amplifier delivers powerful, high-output sound
  • 134 dB SPL maximum output for large venues and live performance use
  • 15" LF driver and 1.75" HF compression driver for full-range audio clarity
  • FIR-X tuning and corrective EQ minimize phase distortion
  • Drive Motion Calibration improves low-frequency accuracy and reliability
  • Advanced DSP modes for FOH and monitor applications with Auto V/H Position
  • Bluetooth audio streaming capability for wireless playback
  • Remote control via the Yamaha D-Remote app for iOS and Android devices
  • Intelligent feedback suppressor reduces unwanted noise automatically
  • Durable, lightweight injection-molded enclosure for portability and strength
  • Optimized port design reduces standing wave interference
  • Large horn design ensures wide and controlled sound dispersion
  • Dual-angle pole mount (0° or -7°) for flexible speaker positioning
  • Built-in rigging points for suspended installations
  • Optional U-bracket for vertical or horizontal mounting
  • Optional protective cover for transport and storage

Specifications

Speaker Type 2-way, Bi-amped Powered Speaker, Bass-reflex
Low-Frequency Driver 15" cone, 3" voice coil
High-Frequency Driver 1.75" diaphragm, 1" throat compression driver
Frequency Range (-10 dB) 46 Hz - 20 kHz
Maximum Output Level 134 dB SPL (peak, IEC noise @ 1 m)
Amplifier Type Class-D
Power Output (Peak) 2000W (LF: 1700W, HF: 300W)
Power Output (RMS) 1000W (LF: 850W, HF: 150W)
Coverage Angle 90° Horizontal x 60° Vertical
Crossover Frequency 1.8 kHz with FIR-X tuning (linear phase FIR filter)
DSP Modes FOH/MAIN, MONITOR, DJ, LIVE MUSIC, SPEECH, OFF
Processing 32-bit/96 kHz A/D and D/A converters
Bluetooth Ver. 5.0, A2DP (SBC, AAC), Class 1
Inputs INPUT1: Combo x1, INPUT2: Combo x1 (Mic/Line selectable)
Mounting/Rigging Pole socket (35 mm, 0° or -7°), Fly points (M10), Optional U-bracket
Color Black
Dimensions (H x W x D) 27.5" (699 mm) x 17.6" (447 mm) x 15" (380 mm)
Weight 46.3 lbs (21 kg)
