Yamaha HS4 4.5" 2-Way Compact Powered Studio Monitors

Home /
Studio & Recording /
Studio Monitors /
Active Powered Monitors /
Yamaha HS4 4.5" 2-Way Compact Powered Studio Monitors - White Pair

Description

Details

Yamaha HS4 4.5-Inch Powered White Studio Monitors

The HS4 in white is a compact studio monitor pair designed for creators seeking accurate, high-quality sound in a small form factor. With a 2-way bass-reflex design, these monitors provide clear, uncolored audio that supports music production, content creation, and general audio monitoring.

Each monitor features a 4.5" cone woofer and 1" dome tweeter powered by a bi-amplified system (26W LF + 26W HF per monitor) for a total of 52W of dynamic power. The flat 60 Hz to 22 kHz frequency response ensures balanced lows, clear mids, and detailed highs. ROOM CONTROL and HIGH TRIM switches on the rear panel allow for acoustic adjustments depending on placement and room characteristics.

Connectivity is flexible, with XLR/TRS combo, RCA, and stereo mini inputs to accommodate a wide range of devices. Front-panel controls provide easy access to power, volume, and headphone monitoring. The HS4 pair comes complete with stereo mini-RCA cable, speaker cables, and anti-slip pads, making setup fast and hassle-free in any compact studio or workspace.

Features

Features

2-way bass-reflex powered studio monitor pair in white
4.5" cone woofer and 1" dome tweeter for clear, balanced sound
Bi-amplified system with 26W LF + 26W HF per monitor
Frequency response 60 Hz to 22 kHz for accurate audio reproduction
ROOM CONTROL and HIGH TRIM switches for room adjustment
XLR/TRS combo, RCA, and stereo mini inputs for flexible connections
Front-panel volume, power, and headphone output for easy use
Compact and lightweight design ideal for small spaces
Includes stereo mini-RCA cable, speaker cables, and anti-slip pads
Sold as a matched white pair for balanced stereo monitoring

Specification

System Type	2-way Powered speaker
Power Type	Bi-amplified (Class-D)
Frequency Response (-10 dB)	60 Hz - 22 kHz
Crossover Frequency	2.3 kHz
Maximum Output Level	102 dB SPL (Measured peak, IEC noise@1m)
Input Connector	L Side: COMBO (XLR/TRS Phone) ×2, RCA ×2, Stereo Mini R Side: Speaker Input
Output Connector	L Side: Headphone, Speaker Output
Enclosure	Bass-reflex type, Material: MDF
Speaker Components	HF: 1" Dome, LF: 4.5" Cone
Nominal Impedance	6Ω
Maximum Output	Dynamic, RL=6Ω: 26W + 26W THD 0.1%, 1 kHz, RL=6Ω: 20W + 20W
Input Impedance	LINE 1 (COMBO): 20 kΩ, LINE 2 (RCA, ST Mini): 10 kΩ
Input Sensitivity (Volume: Maximum)	LINE 1 (COMBO): +4 dBu, LINE 2 (RCA, ST Mini): -10 dBu
Maximum Input	LINE 1 (COMBO): +20 dBu, LINE 2 (RCA, ST Mini): +6 dBu
Color	White
Packaging	Pair
Dimensions (H x W x D)	L Side: 9.45" (240 mm) x 5.91" (150 mm) x 8.39" (213 mm) R Side: 9.45" (240 mm) x 5.91" (150 mm) x 7.99" (203 mm)
Weight	L Side: 8.16 lbs (3.7 kg) R Side: 6.83 lbs (3.1 kg)
