Yamaha MOTIF XF8 88-Key Workstation (Discontinued)

Yamaha MOTIF XF8 88-Key Workstation (Discontinued)

Name: Yamaha MOTIF XF8 88-Key Workstation (Discontinued)
Brand: Yamaha Instruments
SKU: YAMAHA-MOTIF XF8
Price: 3599.99 USD
Availability: OutOfStock

Write a Review

Part #:

MOTIF XF8

Model #:

MOTIF XF8

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Description

Soon after the original MOTIF was released in 2001, it was recognized as the best sounding, top selling and most requested music workstation on the market. Over time, it has continued to evolve and improve its expressiveness and functionality. At the same time, the online community of end users, sound programmers, software developers and product support specialists has expanded into a vibrant online music production community. The MOTIF breathes new life into live performances with its expressive sounds and intuitive control. In music creation, the MOTIF not only offers its own music creation capabilities, it also offers a system for integrating those capabilities with a variety of software applications. And now, the next generation XF builds on the decade-long heritage of MOTIF, and provides groundbreaking expansion capabilities with flash memory that will set a new standard for keyboard workstations for years to come.

Features

Comprehensive high sound quality, including an enormous 741MB of waveforms.
An additional 128 Voices and 8 drum kits, for a total of 1,353 high-quality Voices.
Up to 2GB of additional content available through separately sold flash memory.
Realization of unique instrument performance methods through the XA (Expanded Articulation) tone generation system.
Reproduction of the unique, natural, warm sounds of vintage instruments through VCM effects.
384 types of performances based on approximately 7800 types of arpeggiators.
Enhanced sampling through 128MB of onboard SD-RAM.
The popular FSX (MOTIF XF6/7) and BH (MOTIF XF8) keyboards.
Improvement of usability thanks to the use of a new GUI.
Category Search feature that provides instant access to the Voices you want.
Cubase AI -- a DAW software application from Steinberg.
DAW integration through remote control, an editor software.
Scalability through standard-equipped USB and Ethernet and the FW16E option.

Specifications

Tone Generator	AWM2, with Expanded Articulation
Polyphony	128 notes
Multi Timbral Capacity	16 Parts (internal), Audio Input Parts (A/D, FW), 1 stereo Part
Wave	741 MB (when converted to 16-bit linear format), 3,977 waveforms
Voice	Preset: 1,024 Normal Voices + 64 Drum Kits. GM: 128 Normal Voices + 1 Drum Kit . User: 128 x 4
Performance	User: 128 x 4 (up to 4 Parts)
Filter	18 types
Effect System	Reverb x 9 types, Chorus x 22 types, Insertion (A, B) x 53 types x 8 Parts (up to 16 units)
Samples	Up to 128 Waveforms (Multi Samples).Up to 256 Key Banks per Waveform.Up to 512 Key Banks
Sampling Sources	Analog input L/R, Stereo output (Resampling). FW (available when the FW16E has been installed)
A/D Conversion	24-bit, 64x oversampling
D/A Conversion	24-bit,128x oversampling
Sample Data	16
Sampling Frequency	44.1kHz, 22.05kHz, 11.025kHz, 5.5125kHz (Stereo/Mono). Sampling Frequency via FW
Sampling Memory	Internal SDRAM: 128M
Sample Length	Mono: 32 MB Stereo: 64 MB
Sampling Time	44.1kHz: 6 min. 20 sec. 22.05kHz: 12 min. 40 ec. 11.025kHz: 25 min. 20 sec. 5.0125kHz: 55 min.
Sample Format	Original format, WAV, AIFF
Note Capacity	Approx. 130,000 notes
Note Resolution	480 ppq (parts per quarter note)
Maximum Polyphony	124 notes
Tempo (BPM)	5 – 300
Recording type	Real time replace. Real time overdub (with the exception of the Pattern Chain).
Tracks	Pattern: 16 Phrase tracks. Pattern Chain: Pattern track, Tempo track, Scene track.
Master	User: 128 *8 Zones (Master keyboard settings), Assignable Knob/Slider settings, Program Change Table
Sequence Software compatible with the Remote Control function	Cubase 4 – 5, SONAR 5.2 – 8 For Mac®: Cubase 4 – 5, Logic 7.2 – LogicStudio, Digital Performer 5.1
Controllers	Pitch Bend wheel, Modulation wheel, Ribbon Controller, Assignable Control Sliders x 8
Display	320 x 240 dot, 5.7 inch graphic color backlit LCD
Connectors	OUTPUT L/MONO, R (standard phone jack), ASSIGNABLE OUTPUT L, R (standard phone jack) A/D INPUT L, R
Power Consumption	30W
Dimensions	H 6.6", W 56.65", D 18.35"
Weight	63.7 lbs (28.8 kg)
