Since it's release in 2004 the PM5D has become a standard for digital live mixing, and the first choice of legions of discerning engineers and sound companies throughout the world. Why? Simply because it offers extraordinary sound and versatility in a relatively small, lightweight system that is intuitive to use and delivers unmatched sound, control, and reliably without the need for additional outboard processing gear. Of course programmability and recall capability are of monumental importance in today's live sound scene as well.
It's no exaggeration to state that the PM5D Digital Mixing Console took the digital revolution to a new level. What's more, it offers a system solution that can enhance the entire sound production process from input to output through seamless integration with digital systems including Yamaha's DME series digital mixing engines and AD8HR 8-channel A/D converters with remote controllable preamps. But for applications that require serious I/O capacity there's the PM5D-EX: a PM5D console plus a DSP5D Digital Mixing System that gives you the I/O and processing capacity of two PM5D consoles controlled from a single control surface, plus the added advantages of digital cabling over long distances when necessary. There's virtually no limit to the possible configurations and applications, thanks to open architecture with the flexibility and expandability you need to handle just about any live sound and recording application.- Features
Features
- Versatile Configuration with Flexible I/O Patching Capability
- PM5D-EX Expanded Digital Mixing System for Double I/O Capacity and Processing Power
- Open Architecture for Flexible Live Sound and Recording
- Virtual Soundcheck Capability
- 96-kHz Processing for Superior Sound and Response
- Advanced Analog Circuitry, Including Top-quality Head Amps
- Extensive Channel and Output Functions
- Eight Effect Processors and 12 Graphic EQs
- Optimized for Live Sound Applications
- Software Built on the PM1D Experience
- Channel Move Function
- Universal power supply
- Enhanced Interoperability with External Devices
- Digital Cabling Capability with PM5D-EX
- Supplied PM5D Editor Application for Extended Control and Efficiency
- Solid Security
- Specification
Mixing capability Mixing channels 48 Mono + 8 Stereo GROUP 24 Mix (Group/AUX) busses AUX 24 Mix (Group/AUX) busses MAIN Stereo A, Stereo B MATRIX 8 DCA/VCA 8 (Output grouping also available at Group 7 and 8) Input channel functions Delay, HPF, Attenuator, 4-band PEQ, 2x Dynamics Output channel functions 8-band PEQ, Dynamics On-board processors 8x SPX multi effectors, 12x 31-band GEQ I/O Mic inputs 48 Phantom power +48V DC; ON/OFF per channel Line inputs 4x Stereo, 2x 2tr in AD converter 24-bit; 128-time over sampling Line outputs 36 Omni output, Monitor out and Cue output DA converter 24-bit; 128-time over sampling Digital I/O 3x 2tr in/out, Cascade in/out Expansion slots 4x Mini-YGDAI (16-in/16-out) Control and others To Host(USB), GPI, HA remote, RS422 remote, Time code in, Word clock I/O, 3x Lamp, PCMCIA slot General Specifications Internal processing 32bit, Accumulator: 58bit Sampling frequency rate Internal 44.1kHz, 48kHz, 88.2kHz, 96kHz External 44.1kHz/88.2kHz (-10%) - 48kHz/96kHz (+6%) Signal delay Less than 2.5ms (@48kHz), Less than 1.25ms (@96kHz) Total harmonic distortion Less than 0.05% (20Hz-40kHz) Frequency response 0, +0.5, -1.5dB 20Hz-40kHz Dynamic range DA: 110dB; AD+DA: 108dB Hum & noise level Equivalent input noise -128dBu Residual output noise -86dBu Crosstalk -80 dB Adjacent Input Channels (INPUT1-48) Power requirements Use PW800W Power consumption 600W (when use with PW800W) Accessories Owner’s manual, 3x Gooseneck lamp, DC power cable Dimensions (H x W x D) 11.13" (283 mm) x 61.06" (1551 mm) x 37.38" (950 mm) Net weight 216.1lbs (98 kg) - Reviews
