Yorkville C2285 Coliseum Series 12" 2-Way Installation Loudspeaker (Discontinued)

Name: Yorkville C2285 Coliseum Series 12" 2-Way Installation Loudspeaker (Discontinued)
Brand: Yorkville
SKU: YORK-C2285
Price: 699 USD
Availability: OutOfStock

Write a Review

Part #:

C2285

Model #:

C2285

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Yorkville C2285 Coliseum Series 12" Installation Loudspeaker can be mounted or flown in either a horizontal or vertical orientation and has fly points on all sides, top, and bottom to ensure easy installation in virtually any environment.

Description

Yorkville C2285 Coliseum Series 12-inch Commercial Speaker

The Yorkville C2285 cabinet can be mounted or flown in either a horizontal or vertical orientation and has fly points on all sides, top, and bottom to ensure easy installation in virtually any environment. This 300W 12" / 1" combination has an ABS Waveguide 80° x 50° rotatable horn assembly. CTL protection ensures years of trouble-free operation.

All wooden Coliseum series enclosures are constructed of highly rigid 0.59" (15 mm) Baltic Birch plywood. Their trapezoidal shape is conducive to array mounting and minimizes lobing difficulties. Flypoints are steel reinforced and engineered to allow easy, flexible and safe enclosure suspension.

All enclosures and grilles can be easily refinished and feature a grille clip attachment system for easy removal and recovering. Painstaking attention to design details is evident by features such as the safety screw hidden under the embossed Yorkville logo, which ensures that the grille does not inadvertently come loose.

Features

300W / 8 ohms
12" Woofer / 1" Horn Driver
80° x 50° Rotatable Waveguide Horn
Proven CTL High Frequency Driver Protection
Integrated 3/8" flypoints
Solid 5/8" (15 mm) Plywood Cabinet Construction
All Metal Grille
1/4" and Binding Post Inputs

Specifications

System Type	Two Way
Active or Passive	Passive
Program Power	300W
Nominal Impedance	8 Ohms
Sensitivity	99 dB @1 W /1 m
Max SPL	124 dB
Frequency Response	55 - 16k Hz +/- 3db
Crossover Frequency	2500 Hz
Driver Configuration	12" / 1"
HF Driver(s)	1" Mylar
HF Horn	Rotatable ABS Waveguide
HF Dispersion (°H x °V)	80 x 50 Rotatable
HF Protection	CTL
LF Driver(s)	2 x 8"
Inputs	2 - 1/4" jacks
Inputs - Binding Post	1 pair
Flying Hardware	3/8" x 9
Enclosure Materials	5/8" (15 mm) 11-ply Russian birch
Grille	Perforated Metal
Covering / Finish	Two Part White Epoxy
Optional Covering / Finishes	Special Order
Dimensions (H x W x D)	24" (610 mm) x 17" (430 mm) x 14" (360 mm)
Weight	44.5 lbs (20.2 kg)
