Yorkville CX80P Coliseum Mini Series 8 inch 2 Way Loudspeaker (Discontinued)

Part #:
CX80P
Model #:
CX80P
Availability: No Longer Available
Contact us for comparable solutions.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL

The Yorkville CX80P Coliseum Mini Series 8 inch 2 Way Loudspeaker is the ideal compact active cabinet for small PA applications where maximum mobility, reliability and high quality loudspeaker performance is required.


Description

The CX80P is the ideal compact active cabinet for small PA applications where maximum mobility, reliability and high quality loudspeaker performance is required.

Designed for mobility, the CX80P's cabinet is made from a rugged ABS plastic, and features an integrated standard 1 3/8" loudspeaker standmount adaptor. The power amplifier module delivers 100 W to the CX80P's 8" driver and 1" mylar tweeter. A 1/4" TRS balanced line input is included for direct connectivity to any source, as well as an auxiliary thru-put for connecting multiple CX80P's together for larger applications. Controls on the power module include Gain, Volume and Tone, with switchable mic/line input sensitivity.

The CX80P is perfectly suited to applications where additional compact and unobtrusive cabinets need to be added to a larger system for even sound distribution and can easily be used as delayed repeater cabinets in large halls. The CX80P can operate at either 115 V / 230 V voltage, making it the ideal solution for highly mobile PA applications, demonstration stations or mobile presentation and public address systems.

Features

  • Ultra Compact Active Two-Way Loudspeaker
  • 8" Woofer / 1" Mylar Dome Tweeter
  • 100 Watt Integrated Amplifier
  • 1/4" TRS Balanced Inputs
  • Accepts Microphone or Line Level Inputs
  • Gain, Volume and Tone Controls
  • Heavy Duty ABS Plastic Cabinet and Metal Grille
  • Integrated Standmount Adaptor

Specifications

System Type 2 Way
Active or Passive Active
Program Power (Watts) 100
Max SPL (dB) 113
Frequency Response (Hz +/- 3db) 60 - 20k
Driver Configuration 8" / 1" dome tweeter
HF Driver(s) 1" Mylar Dome Tweeter
LF Driver(s) 8"
Total Power (Watts) 100
Cooling Scheme Heat Sink
Power Cable Built-in
Inputs 2 x 1/4" TRS (Input/Aux Out)
Inputs - 1/4 1 TRS
Mixer Controls Mic/Line sensitivity switch Gain, Tone, Volume controls
Other Controls / Features Switchable AC voltage 115/230
Pole Mount Adapter 1 3/8" - 3.5 cm
Enclosure Materials ABS Plastic
Grille Perforated Metal
Dimensions (H x W x D) 16.25" (420 mm) x 9.75" (250 mm) x 11.25" (285 mm)
Weight 18.7 lbs (8.5 kg)
