The NX18SP is a high-performance 18-inch powered subwoofer built for professional sound reinforcement. Designed as the first 18" subwoofer in the NX series, it delivers rich, powerful bass in a compact, road-ready enclosure. With 2400W peak output and a 4" voice coil, the NX18SP provides deep low-end extension for live music, DJs, and large-scale events.
Engineered to pair seamlessly with NX series speakers, we recommend using one NX18SP with a pair of NX8Ps or two NX18SPs with a pair of NX12Ps for maximum sound coverage. The NX18SP can also enhance any full-range system, giving audio engineers and performers flexibility to create a robust, professional PA setup.
Featuring three selectable voicing modes — Punch, Smooth, and Deep — the NX18SP allows you to tailor your low-end response to the venue and music style. Dual combi-jack inputs and dual XLR link outputs make setup fast and easy, while the durable enclosure ensures road-tested reliability for touring or installation applications.
| System Type | Bass Reflex Powered Subwoofer |
|---|---|
| Power Rating | 2400W Peak (1200W Program) |
| Max SPL | 134 dB Peak |
| Frequency Response | 35 Hz - 100 Hz (Hz +/- 3 dB) |
| LF Driver(s) | 18" with 4" Voice Coil |
| LF Amplifier Type | Class D |
| Cooling Scheme | Variable Speed Controlled Fan |
| In/Out Connections | 2x XLR Link Outputs |
| Inputs | 2x Combi-Jack (XLR / 1/4") |
| Level Controls | Master - Sub Level |
| Bar Handles | 2 (1x Each Side) |
| Pole Mount Adapter | 1x 1 3/8", 3.5 cm (Top) |
| Enclosure Materials | 15 mm Birch |
| Covering/Finish | Paint |
| EQ Controls | Punch, Smooth, and Deep Modes |
| Dimensions (H x W x D) | 24.8" (629.92 mm) x 20.5" (520.7 mm) x 26.6" (675.64 mm) |
| Weight | 104 lbs (47.25 kg) |
