Yorkville YX18SC Passive Subwoofer (Discontinued)

Part #:
YX18SC
Model #:
YX18SC
Availability: No Longer Available
Contact us for comparable solutions.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL

The passive YX18SC uses the tried and true vented 18-inch front loaded bass reflex subwoofer design. The internal passive crossover allows the 400-watt YX18SC to be added to any system without additional external processing.

Description

The passive YX18SC uses the tried and true vented 18-inch front loaded bass reflex subwoofer design. The internal passive crossover allows the 400-watt YX18SC to be added to any system without additional external processing.

Solid plywood cabinet construction ensures the YX18SC will remain rattle and buzz-free at the high volumes a subwoofer must endure. Integrated pole mount adaptor allows full range loudspeakers like the YX15 or YX15P to be raised above the crowd easily and effectively with a simple subwoofer stand or speaker pole.

Designed with working musicians in mind, the YX18SC offers rugged 5/8-inch plywood cabinet construction, all metal bar handles, metal input plate, integrated speaker mounts and a custom punched, perforated metal grille to protect the speaker.

Features

  • 400 Watt Subwoofer
  • 18-inch Woofer
  • Bass Reflex Cabinet Design
  • 6 Ohm Design for Easy Amplifier Configuration
  • 45Hz - 150Hz Frequency Response
  • Internal Passive Low-Pass Filter for Plug-And-Play Simplicity
  • 2 x Speakon™ and 2 x 1/4-inch Parallel Inputs
  • Integrated All Metal Speaker Pole Mount Adaptor
  • Solid 5/8-inch (15mm) Plywood Construction

Specifications

Active or Passive Passive
Program Power (Watts) 400
Nominal Impedance (Ohms) 6
Sensitivity (dB @1Watt/1m) 98
Max SPL (dB) 124
Frequency Response (Hz +/- 3db) 45 - 150
Crossover Frequency (Hz) 150
LF Driver(s) 18 inch
LF Program Power (Watts) 400
Inputs - 1/4 2
Inputs - Speakon 4-pin 2
Other Controls / Features Built-in passive low-pass filter for Plug-and-play simplicity
Corners Metal
Feet Plastic Glides
Bar Handles 2 (Side)
Pole Mount Adapter (1 3/8 Yes (Top)
Enclosure Materials 15mm (5/8inch) Plywood
Grille Custom Punched Black Perforated Metal
Covering / Finish Black Ozite
Dimensions (H x W x D) 25" (63.5 cm) x 22" (55.9 cm) x 26" (66 cm)
Weight 74 lbs/ 33.6 kg
