Yorkville LS2100P 21 inch Elite Series Powered Subwoofer (Discontinued)

Yorkville LS2100P 21 inch Elite Series Powered Subwoofer (Discontinued)

Name: Yorkville LS2100P 21 inch Elite Series Powered Subwoofer (Discontinued)
Brand: Yorkville
SKU: YORK-LS2100P

Write a Review

Part #:

LS2100P

Model #:

LS2100P

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Yorkville LS2100P 21 inch Elite Series Powered Subwoofer's integrated amplifier delivers 3600 watts (Peak) into a 21-inch long excursion neodymium woofer with 6-inch voice coil.

Description

Built for even the most demanding club or concert setting, the élite LS2100P delivers solid deep bass and solid punch in this fully powered version of the popular LS2104. The integrated amplifier delivers 3600 watts (Peak) into a 21-inch long excursion neodymium woofer with 6-inch voice coil. XLR and 1/4-inch TRS input capable of handling line or speaker level ensures the LS2100P can be easily integrated into virtually any medium to large scale PA needing additional bottom end support with a minimum of effort.

Features

Integrated 3600 Watt Amplifier (Peak - 2400 Watts Program)
21-inch Woofer with 6-inch Voicecoil
Max SPL 144dB Peak (135dB Continuous)
High Performance Mid-Sized Subwoofer Design
33Hz - 150Hz with Adjustable HF Roll-Off
45Hz - 90Hz Variable Boost Frequency
Paralleled XLR and 1/4-inch Selectable Line or Speaker Level Inputs
Excursion, Peak and Thermal Woofer Protection
Integrated All Metal Speaker Pole Mount Adaptor
Solid 5/8-inch (15mm) Birch Plywood Construction
All-Metal Grille & Integrated Bar Handles

Specifications

System Type	Rear Horn-Loaded
Active or Passive	Active
Program Power (Watts)	2400
Max SPL (dB)	135
Frequency Response (Hz +/- 3db)	32 - 200
Driver Configuration	21-inch Neodymium Driver with 6-inch Voice Coil
LF Protection	Thermal / Overcurrent / Clip
LF Power Amplifier (Watts)	2400
Power Cable	Detachable
Power Consumption (typ/max)	800/1440VA (12A @ 60hz, 6A @ 50hz)
Inputs - 1/4	2 line/speaker level inputs, 2 link (in/out)
Inputs - XLR	2 line inputs, 2 link (in/out)
Level Controls	Master
Other Controls / Features	Active Controls: Level Low Pass Filter Frequency Bass Boost Level
Corners	Metal
Feet	Rubber
Wheels	Rear tilt-back
Bar Handles	6 (Side), 2 (Top)
Pole Mount Adapter (1 3/8	1 (Top)
Enclosure Materials	3/4 inch 7-ply Spruce
Grille	Perforated Metal
Covering / Finish	Black Ozite (Carpet)
Optional Covering / Finishes	Black Ultrathane Paint (LS2100PB)
Dimensions (H x W x D)	36" (94.1 cm) x 25.25" (64.1 cm) x 31" (78.7 cm)
Weight	203 lbs (92.1 kg)
