MIPRO MRM-70B Single-Channel UHF Diversity Receiver Module

Description

Details

The easy to install and use plug-and-play MRM-70B receiver module is designed mainly to fit MIPROs wireless portable PA systems for wireless microphone applications. Other unique installations can be considered for PA amplifiers, mixers, signal processors, and active speakers.

Features

Features

Advanced diversity technology for optimum reception quality
Preset with 16 auto-scannable frequencies
One-touch Scan for a clear, interference-free frequency
One-touch ACT™ syncs the transmitter and receiver frequency automatically
Easy-to-read LED channel display
Interference warning indicator
"Sensitivity" adjustor can be adjusted to minimize interference
Dual "PiloTone and NoiseLock" circuits minimize interference
5-segment RF and Audiometers
Modular design allows easy installation and replacement
When installed, master level control enables volume be wirelessly controlled by an ACT-32HR transmitter microphone instead of a separate remote (MA-708 & MA-808 portables)

Specification

Frequency Range	UHF 480 - 934 MHz
Bandwidth	24 MHz
Preset Channels	16
Receiving Mode	CPU-controlled Diversity Receiving
Oscillation Mode	PLL Synthesized. Frequency Stability ≤ ±0.005% (-10ºC + 60ºC)
Sensitivity	10 dB µ V at S/N > 80 dB
Spurious Emissions	< 82 dB
S/N Ratio	> 100 dBA
T.H.D.	< 0.5% @ 1 kHz (Dev. + 32 kHz)
Frequency Response	60 Hz ~ 15 kHz (Overall system)
Squelch Control	"PiloTone & NoiseLock" dual-squelch circuits
Audio Output	610 mV rms
Power Supply	12 – 15 V DC
Current Consumption	< 250 mA
Operating Temperature	-10~+60℃
Dimensions (H x W x D)	1.4" (35 mm) x 3" (75 mm) x 5.6" (141 mm)
Weight	Approx. 0.275 lbs (0.125 kg)
