AKG PZM11 Boundary Layer Microphone
Part # 3326H00010
Model # PZM11

The AKG PZM11 is a Pressure Zone Microphone designed for conference-room, security and surveillance applications and can be mounted in the ceiling or wall in a standard electrical outlet box.

Availability: Usually arrives in 5-9 business days.

Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email [email protected] or call us at 888-256-4112.

Need Quantity Pricing?

We provide quantity discounts for contractors & installers, schools, government, and military buyers on select brands and products.

Talk To An Engineer

Description

Details

The AKG PZM11 is a Pressure Zone Microphone designed for conference-room, security and surveillance applications. It can be mounted in the ceiling or wall in a standard electrical outlet box. Providing excellent intelligibility, the PZM11 is designed to look like a light switch so as not to draw attention.

The PZM11 has a mic level output and is powered by 12-48V phantom power. Like other Pressure Zone Microphones, the PZM11 utilizes the Pressure Recording Process in which a miniature condenser microphone capsule is mounted very close to a sound-reflecting plate or boundary. The capsule is mounted in the “Pressure Zone” just above the boundary, a region where sound coming directly from the sound source combines in-phase with sound reflected off the boundary. The benefits are a wide, smooth frequency response free of phase interference, excellent clarity and “reach,” and consistent pickup anywhere around the microphone. In the PZM11 low frequencies below the voice range is rolled off to reduce pickup of air-conditioning rumble. The high frequency response is boosted slightly to aid clarity and articulation. The microphone connector is a row of screw terminals for easy installation. The output is balanced, low impedance, which allows long cable runs without hum pickup or high-frequency loss.

Features

Features

  • PZM Microphones are designed for security, surveillance, and conference-table use
  • Since they do not look like microphones, they are inconspicuous
  • It can be mounted in the ceiling or wall in a standard electrical outlet box. Providing excellent intelligibility
  • PZM-11 uses miniature mic capsule mounted very near a sound-reflecting plate or boundary
  • 245 ohms, balanced impedance
  • Off-white May be painted any color; take care to first seal the opening between the capsule and boundary plate
Specification
ElementElectret condenser
Frequency Response (typical)80 Hz to 20,000 Hz
Polar PatternHemispherical
Impedance225 ohms, balanced
Open Circuit Sensitivity5 mV/Pa (–46 dBV/Pa)
Power Sensitivity–45.5 dBm/Pa
Equivalent Noise Level (self-noise)26 dB SPL typical (0 dB = .0002 dyne/cm2), A-weighted
S/N Ratio68 dB at 94 dB SPL
Maximum SPL120 dB SPL produces 3% THD
Output ConnectorThree screw terminals, 1 = ground, 2 = audio hot (in polarity), 3 = audio cold (opposite polarity)
PolarityPositive pressure on the diaphragm produces a positive voltage on screw terminal 2
Operating VoltageStandard phantom power, 12 to 48V DC on screw terminals 2 and 3 with respect to screw terminal 1
Current Drain400 microamperes
MaterialsSteel plate and high-impact plastic capsule holder
FinishOff-white. May be painted any color; take care to first seal the opening between the mic capsule
Dimensions (H x W x D)1.14" (29 mm) x 2.76" (70 mm) x 4.53" (115 mm)
Net Weight0.15 lbs (71 g)
