AKG Sound Grabber II Boundary Layer Microphone (Discontinued)

Part #:
3321H00010
Model #:
Sound Grabber II
Availability: No Longer Available
Contact us for comparable solutions.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL

The AKG Sound Grabber II is an updated version of the original Sound Grabber and utilizes the same Pressure Zone Microphone technology in which sound waves reinforce themselves in the area nearest a flat surface.

Description

The AKG Sound Grabber II is an updated version of the original Sound Grabber. It utilizes the same Pressure Zone Microphone technology in which sound waves reinforce themselves in the area nearest a flat surface, usually referred to as the boundary. Top recording engineers all over the world are using professional versions of the AKG PZM (Pressure Zone Microphone) to improve the quality of their recordings.

The Sound Grabber II is one version of that technology, designed to meet the needs of the home or business recordist and bring the benefits of PZM technology within the reach of many more people. Because of this new technology, Sound Grabber II offers you the opportunity for vast improvement in the quality of your recordings. The Sound Grabber II will pick up sounds at distances you never thought possible and it will pick them up with a clarity that other microphones, because of the limitations of their construction, simply cannot match. The Sound Grabber II does not need to follow the action, since it has a wide-angle pickup pattern. So long as the mic "sees" the sound, in whatever direction or angle, it will pick it up clearly; it does not need to be between you and the other person. Speakers or vocalists can move freely around the Sound Grabber II without their tone quality changing. For your greatest enjoyment of the Sound Grabber II, we urge you to read these instructions thoroughly so you can be familiar with this new technology.

Features

  • PZM design makes the sound clearer and more natural
  • Ideal for recording conferences, interviews, home videos
  • One AAA Alkaline battery
  • Medium-impedance unbalanced output
  • 1/4" phone, 3.5mm phone, or 2.5 mm phone connector

Specifications

Transducer Electret condenser
Frequency Response (typical) 50 Hz to 16 kHz
Polar Pattern Hemispherical (half-omni) on a largesurface
Impedance 1,600 ohms, unbalanced. Recommended minimum load impedance 10,000 ohms
Open-Circuit Sensitivity 20 mV/Pa (-54 dBV/Pa)
Power Sensitivity –42 dBm
Equivalent Noise Level (self noise) 21 dB SPL typical, A-weighted (0 dB = .0002 dyne/cm2)
S/N Ratio 73 dB at 94 dB SPL
Maximum SPL 120 dB SPL produces 3% distortion
Cable 10 foot with mini phone plug, 1/4” phone plugand micro phone plug adapters
Power One 1.5V AAA alkaline battery
Battery Life Approximately 45 days
Current Drain 0.5 mA
Materials High-impact plastic housing
Finish Satin black
Included Accessories 1.5V AAA battery, 1/4” phoneplug adaptor, 3.5 mm to 2.5 mm adaptor
Dimensions (H x W x L) 0.74" (19 mm) x 3.43" (87 mm) x 5.9" (150 mm)
Weight 0.25 lbs (115 grams)
