The Alfatron ALF-20X-SDIC full HD PTZ camera is designed for meeting rooms, boardrooms, conference venues, and houses of worship. It features 1080p video up to 60 fps, a 20x zoom lens, AI-powered auto-tracking, NDI connectivity, and HDMI, SDI, USB 3.0, and LAN interfaces for flexible video conferencing and streaming setups.

Description

Alfatron ALF-20X-SDIC Full HD PTZ Camera (White)

The ALF-20X-SDIC is a white full HD 1080p PTZ camera equipped with a 20x zoom lens. This PTZ camera is suitable for medium- to large-sized meeting rooms, boardrooms, conference venues, and houses of worship. The Alfatron ALF-20X-SDIC is compatible with video meeting software such as Microsoft Teams and Zoom. The Full HD 1080p camera supports high-quality video streaming and high-definition real-time synchronization.

Features 1080p video at frame rates up to 60 fps, NDI connectivity, a 20x zoom lens, AI-powered auto tracking, and autofocus technology. Additional features include low noise, a high signal-to-noise ratio (SNR), quiet pan-tilt-zoom movement, and 255 presets. It supports multiple network protocols, including ONVIF, RTSP, and RTMP, as well as VISCA IP, ONVIF, PELCO-D, PELCO-P, and standard VISCA control protocols. Its field of view ranges from 3.3° (telephoto) to 54.7° (wide).

Connectivity options include USB 3.0, HDMI, SDI, CVBS, LAN, RS-232, and audio input. The camera includes an IR remote control and supports PC control using Sony VISCA or Pelco-D/P commands. It can be powered by 12V DC or PoE and ships with either a ceiling or wall mount bracket. The white finish makes it suitable for installations where the camera's appearance should blend with the surrounding environment.


Most Alfatron products come with a 7-year limited warranty. Register your product with Alfatron to receive an additional 3-year extended warranty on eligible products, for 10 years of total coverage.

Features

  • 1080p video with a frame rate up to 60 fps (interlaced not supported)
  • NDI connectivity
  • 20x zoom lens provides a clear and fluent image
  • AI-powered auto tracking
  • Leading autofocus technology
  • Low noise and high SNR
  • Quiet PTZ movement
  • 255 presets
  • Supports multiple network protocols, including ONVIF, RTSP, and RTMP
  • Control protocols include VISCA IP, ONVIF, PELCO-D, PELCO-P, and standard VISCA protocols
  • Field of view: 3.3° (telephoto) to 54.7° (wide)
  • USB 3.0, HDMI, SDI, CVBS, LAN, RS-232, and audio input; supplied with an IR remote control
  • PC control using Sony VISCA or Pelco-D/P commands
  • Powered by 12V DC or PoE
  • Ships with either a ceiling or wall mount bracket
  • White finish
  • 7-Year limited warranty + 3 additional years with registration

Specifications

Optical Zoom 20x
Focal Length f=5.5~110 mm
Sensor 1/2.8-inch-high quality HD CMOS sensor
Effective Pixels 16: 9, 2.07 megapixels
Video Format HDMI/SDI video format
1080P60/50/30/25/59.94/29.97, 1080I60/50/59.94, 720P60/50/30/25/59.94/29.97
USB3.0 interface video format: 1920x1080 @ 60 fps Max
View Angle 3.3°(tele)
54.7°(wide)
AV F1.6 - F3.5
Digital Zoom 10x
Minimum Illumination 0.5 Lux (F1.8, AGC ON)
DNR 2D & 3D DNR
White Balance Auto/Manual/One Push/3000K/3500K/4000K/4500K/5000K/5500K/6000K/6500K/7000K
Focus/Aperture/Electronic Shutter Auto/Manual/One Push Focus
Iris Auto/Manual
Shutter Auto/Manual
BLC ON/OFF
WDR OFF/ Dynamic level adjustment
Video Adjustment Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve
SNR >55 dB
Video Interfaces ALF-20X-SDIC Interfaces: USB3.0 (compatible with USB2.0), HDMI, SDI, LAN (POE), RS232-IN/OUT, RS422(compatible with RS485), A-IN, Rotary dial code, on-off switch
Video Output HDMI, SDI, LAN, USB3.0, USB2.0
Video Stream Dual stream output
Video Compression Format LAN Interface: H.265, H.264, Dual stream output
USB2.0 Interface: H.265, H.264, MJPEG
USB3.0 Interface: YUV
Audio Input Interface Double-track 3.5 mm linear input
Audio Output Interface HDMI, SDI, LAN
Audio Compression Format AAC/MP3/G.711A
Network Protocol RTSP, RTMP, ONVIF, GB/T28181, supports network VISCA control protocol
Supports remote upgrade, remote restart, remote reset
Control Interface RS232, RS485
Control Protocol VISCA/Pelco-D/Pelco-P, Baud Rate: 115200/9600/4800/2400 bps
Pan/Tilt Rotation ±170°, -30°~+90°
Pan Control Speed 0.1 -60°/sec
Tilt Control Speed 0.1-30°/sec
Preset Speed Pan: 60°/sec, Tilt: 30°/sec
Preset Number 255 presets (10 presets by remote controller)
Power Interface HEC3800 outlet (DC12V), POE
Input Voltage DC12V±10%
Input Electric Current Maximum: 1A
Power Consumption Maximum: 12W
Stored Temperature -10°C~+60°C
Storage Humidity 20%~95%
Working Temperature -10°C~+50°C
Working Humidity 20%~80%
Dimensions (H x W x D) 5.94" (150.9 mm) x 7.01" (178 mm) x 4.55" (115.5 mm)
Weight 3.04 lbs (1.38 kg)

DOCUMENTS

In The Box

  • (1) ALF-20X-SDIC Full HD PTZ Camera in White
  • (1) 12V/1.5A Power Supply
  • (1) RS232 Control Cable
  • (1) USB3.0 Connection Cable
  • (1) USB2.0 Connection Cable
  • (1) Remote Controller
  • (1) Ceiling or Wall Mount Bracket
  • Manual
  • Warranty Card
