Alfatron ALFC-406 4" 2-Way 20W 70V/100V/8-Ohm Flush-Mount Loudspeaker with Backbox - White

Part #:
ALFC-406
Model #:
ALFC-406
Availability: Usually arrives in 5-9 business days. Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL

The Alfatron ALFC-406 is a 4" 2-way flush-mount loudspeaker with backbox, delivering 20W power handling with 70V, 100V, and 8Ω operation. It features a 4" PP woofer, 1" Mylar high-frequency driver, 90 Hz to 20 kHz response, and 87 dB sensitivity in a white ABS enclosure.

Description

Alfatron ALFC-406 4-Inch 2-Way 20W Flush-Mount Loudspeaker

The ALFC-406 is a compact 4" 2-way flush-mount loudspeaker with an integrated backbox, designed for clean, discreet installation in commercial indoor audio environments. Its flush-mount form factor provides a streamlined appearance while the white ABS construction and powder-coated iron mesh grille complement a wide range of ceiling and architectural interiors.

The speaker delivers 20W of power handling and supports 70V, 100V, and 8Ω operation, making it suitable for both distributed commercial audio systems and conventional low-impedance applications. Selectable power taps include 20W, 10W, 5W, 2.5W, and 8Ω, while the 4" PP woofer and 1" Mylar high-frequency driver provide a 90 Hz to 20 kHz frequency response with 87 dB sensitivity at 1W/1M for clear, balanced audio reproduction.

Designed for practical installation, the speaker features a 180 mm diameter mounting hole and measures 200 mm in diameter by 150 mm deep. The backbox is included for a complete flush-mount installation, while the durable ABS enclosure and powder-coated grille provide a professional finish for classrooms, offices, retail spaces, meeting rooms, and other indoor commercial applications.

Features

  • 2-way 4" flush-mount loudspeaker with included backbox
  • 20W power handling with 8Ω operation
  • 70V/100V transformer taps at 20W, 10W, 5W, and 2.5W
  • Wide 90 Hz to 20 kHz frequency response
  • 87 dB sensitivity at 1W/1 m
  • 4" polypropylene woofer for clear, balanced low-frequency reproduction
  • 1" Mylar tweeter for detailed high-frequency performance
  • ABS panel and cover construction for durability
  • Powder-coated iron mesh grille for added protection
  • White finish for discreet installation in commercial and architectural spaces
  • Supports 100V, 70V, and 8Ω line input configurations
  • Flush-mount design for clean, space-saving ceiling installation
  • Designed for indoor applications and is not weatherproof
  • Supplied with a backbox for convenient installation

Specifications

Frequency Response 90 - 20 kHz
Sensitivity 87 dB (SPL/1W @ 1 m)
Nominal Coverage Angle 150°
Power Handling 20W
Power Taps 20W / 10W / 5W / 2.5W / 8Ω
Line Input 100V / 70V / 8Ω
Material ABS (Panel and Cover)
Grille Powder Coated Iron Mesh
Component 4" PP Woofer (L. Speaker)
1" Mylar (H. Speaker)
Color White
Voice Coil Size 25.9 x 0.17 mm - 2 Layers
DC Impedance 7Ω
Former ASV
Magnet Ferrite (305 g/0.6 lbs)
3.1" (80 mm) x 1.2" (32 mm) x (0.5") 15 mm (Y30)
Basket Iron
Cone Material PP
Spider Cloth
Dimensions (Dia x H) 7.8" (200 mm) x 5.9" (150 mm)
Weight 3.9 lbs (1.8 kg)
