The Allen & Heath ZED-10FX is an amazing little desk for small band mixing. It is ultra portable for carrying to the gig, and can be used for recording live or in the studio. It comes with configurable USB audio in/out making it easy to capture stereo recordings.
Guitars can be plugged in directly to the mixer using the specially designed high-impedance inputs, while the mixer has two stereo inputs for MP3/CD players or keyboards. Equipped with professional XLR stereo outputs and a flexible monitoring section with headphone and speaker feed outputs. We’ve added a set of fabulous effects to give shimmering reverbs and enhance your sound.
ZED-10FX has an essential selection of 16 time-delay effects, designed for small groups who don’t want to carry around an effects unit with their gear but who still want great quality FX at their gigs and on their recordings. Our DSP engineers worked hard, crafting and refining beautiful reverb algorithms to enhance every performance. These effects are available nowhere else at this price point – this quality and integration is only available from the ZED-FX. ZED effects are easily controlled using 3 buttons with 9 display LEDs. For example, the ideal delay time can be quickly tapped-in, or the perfect amount of reverb on the lead vocal can be dialled-in. There is one-stop navigation and editing – in fact, it’s just as easy as using effects pedals. To alter effects parameters, the TAP button is held down and the up/down buttons pressed to adjust the specific parameter for that effect, for example, the decay length on PLATE, or the depth on CHORUS.
| Inputs | Mono channel (XLR) Input -10 to –60dBu for nominal (+11dBu in max) Mono channel Line Input (Jack socket) +10 to –40dBu (+31dBu maximum) Stereo Input (Jack or phono sockets) 0dBu nominal (control = Off to +15dB) |
|---|---|
| Output | L/R Outputs ( XLR) 0dBu nominal. +21dBu maximum Aux & FX Outputs (Jack sockets) 0dBu nominal. +21dBu maximum Record & Monitor Outputs (phono sockets) 0dBu nominal. +21dBu maximum |
| Frequency Response | Mic in to Mix L/R Out, 30dB gain +0.5/-1dB 10Hz to 30kH Line in to Mix L/R out 0dB gain +0.5/-1dB 10Hz to 30kH Stereo in to Mix L/R out +0.5/-1dB 10Hz to 30kH |
| THD+n | Mic in to Mix L/R Out, 10dB gain 1kHz +10dBu out 0.002% Mic in to Mix L/R Out, 30dB gain 1kHz 0.01 Line in to Mix L/R out 0dB gain 0dBu 1kHz 0.003% Stereo in to Mix L/R out 0dB gain +10dBu 1kHz 0.002% Gtr Input to Mix L/R Out, 0dBu, Boost OUT 0.015% Gtr Input to Mix L/R Out, 0dBu, Boost IN 2% Second Harmonic |
| Headroom | Analogue Headroom from nominal (0Vu) 21d USB in & out headroom from nominal (0Vu) 14d |
| Noise | Mic Pre EIN @ max gain 150R input Z 22-22kHz -127dBu Mix L/R out, L/R faders = 0, Levels min, 22-22kHz -96dB Mix L/R out, L/R faders = 0, Levels min, 22-22kHz -96dB |
| USB Audio CODEC (Coder/Decoder) | USB Audio In/Out USB 1.1 compliant 16bit Sample Rate 32, 44.1, or 48kH |
