The Allen & Heath ZED-12FX is ideal for groups who need to travel light. Even with its small footprint, the 12FX squeezes in 4 auxiliary channels and swept semi-parametric EQ on top of the already impressive feature set including configurable USB audio in/out makes it easy to capture stereo recordings.
ZED-12FX features a responsive 3-band, swept mid frequency EQ design which utilises MusiQ – with optimised slope (or Q factor) for equalising individual instruments.
ZED-12FX has an essential selection of 16 time-delay effects, designed for small groups who don’t want to carry around an effects unit with their gear but who still want great quality FX at their gigs and on their recordings. Our DSP engineers worked hard, crafting and refining beautiful reverb algorithms to enhance every performance. These effects are available nowhere else at this price point – this quality and integration is only available from the ZED-FX. ZED effects are easily controlled using 3 buttons with 9 display LEDs. For example, the ideal delay time can be quickly tapped-in, or the perfect amount of reverb on the lead vocal can be dialled-in. There is one-stop navigation and editing – in fact, it’s just as easy as using effects pedals. To alter effects parameters, the TAP button is held down and the up/down buttons pressed to adjust the specific parameter for that effect, for example, the decay length on PLATE, or the depth on CHORUS.
| Model | ZED-12FX |
|---|---|
| Product Type | Recording Mixer |
| Operating Level Inputs | Specifications |
| Mono channel (XLR) Input | +6 to –63dBu for nominal (+17dBu in max) |
| Mono channel Line Input (Jack socket) | +10 to –26dBu (+30dBu maximum) |
| Insert point (TRS Jack socket) | 0dBu nominal +21dBu maximum |
| Stereo Input (Jack sockets) | 0dBu nominal (control = Off to +10dB) |
| Stereo input (phono sockets) | 0dBu nominal (control = Off to +10dB) |
| Operating Level Outputs | Specifications |
| L, R & Mono Outputs (L&R XLR, Mono Jack) | 0dBu nominal. +21dBu maximum |
| Aux Outputs (Jack sockets) | 0dBu nominal. +21dBu maximum |
| Alt Outputs (phono sockets) | 0dBu nominal. +21dBu maximum. |
| Rec Outputs (phono sockets) | 0dBu nominal. +21dBu maximum. |
| Frequency Response | Specifications |
| Mic in to Mix L/R Out, 30dB gain | +0.5/-1dB 20Hz to 20kHz. |
| Line in to Mix L/R out 0dB gain | +0.5/-1dB 10Hz to 30kHz |
| Stereo in to Mix L/R out | +0.5/-1dB 10Hz to 30kHz |
| THD+n | Specifications |
| Mic in to Mix L/R Out, 0dB gain 1kHz +10dBu out | 0.004% |
| Mic in to Mix L/R Out, 30dB gain 1kHz | 0.014% |
| Line in to Mix L/R out 0dB gain 0dBu 1kHz | 0.005% |
| Stereo in to Mix L/R out 0dB gain +10dBu 1kHz | 0.003% |
| Headroom | Specifications |
| Analogue Headroom from nominal (0Vu) | 21dB |
| USB in & out headroom from nominal (0Vu) | 14dB |
| USB Audio CODEC (Coder/Decoder) | Specifications |
| USB Audio In/Out | USB 1.1 compliant 16bit |
| Sample Rate | 32, 44.1, or 48kHz |
| Noise | Specifications |
| Mic Pre EIN @ max gain 150R input Z 22-22kHz | -127dBu |
| Mix L/R out, L/R faders = 0, 22-22kHz | -88dBu |
| Weight (Unpacked) | 14.3 lbs |
| Weight (Packed) | 23.0 lbs |
