Alto TS215S 1250W 15 inch Powered Subwoofer

Home /
Alto TRUESONIC 2 TS215S 1250W 15" Powered Subwoofer (Discontinued)

Description

Details

For those performance situations where additional low-frequency output and punch are required, even beyond the already-impressive bass capability of the TS2 full-range speakers, the new TS2 powered subwoofers are the perfect solution.

Pair TS215S with any full-range speaker system to extend the bass response and dramatically enhance the overall impact of the music being played.

Features

Features

1250 watts of peak power output
Custom engineered high-efficiency Class D amplifiers with passive cooling design – no fan means the speaker runs cleaner, quieter and has greater long-term reliability
15-inch high-excursion woofer
(2) XLR+1/4-inch combo inputs + (2) balanced XLR line outputs
Polarity Reverse, Full-Range Output and Extended LF controls
Electronic clip, thermal and transducer overdrive protection
Rugged, internally-braced front-ported plywood cabinet
Integrated 35mm speaker pole socket

Specification

Output Power	1250W Peak, 625W Continuous
Transducer Low	15" (381 mm) Woofer, 3" (76 mm) Voice Coil
Frequency Response	35–95 Hz (-10 dB)
Maximum SPL	129 dB (@ 1 m)
Connections	(2) XLR+1/4" (6.35 mm) Inputs; (2) XLR Outputs; (1) IEC Power Cable Input
Input Level	Line +4 dBu (Nominal)
External Controls	Volume Control, Signal/Clip Limiter with LED, Polarity-Reverse Switch, High-Pass Filter Bypass Switch with LED, Extended Low-Frequency Switch with LED, Power Switch with LED
Electronic Protections	Electronic Clip, Thermal and Transducer Overdrive Protection
Enclosure	Internally Braced Plywood Cabinet; 35 mm Mounting Pole Socket on Top Panel
Power	Connection: Standard IEC Cable Input Voltage: 110–120, 220–240 V AC; 50/60 Hz Consumption: 450W Fuse: T6.3AL AC250V (110–120 V) or T3.15AL AC250V (220–240 V)
Dimensions (H x W x D)	24.8" (630 mm) x 21.34" (542 mm) x 20.3" (515 mm)
Weight	62 lbs (28.2 kg)

Documents
