- Description
Details
For those performance situations where additional low-frequency output and punch are required, even beyond the already-impressive bass capability of the TS2 full-range speakers, the new TS2 powered subwoofers are the perfect solution.
Pair TS215S with any full-range speaker system to extend the bass response and dramatically enhance the overall impact of the music being played.
- Features
Features
- 1250 watts of peak power output
- Custom engineered high-efficiency Class D amplifiers with passive cooling design – no fan means the speaker runs cleaner, quieter and has greater long-term reliability
- 15-inch high-excursion woofer
- (2) XLR+1/4-inch combo inputs + (2) balanced XLR line outputs
- Polarity Reverse, Full-Range Output and Extended LF controls
- Electronic clip, thermal and transducer overdrive protection
- Rugged, internally-braced front-ported plywood cabinet
- Integrated 35mm speaker pole socket
- Specification
Output Power 1250W Peak, 625W Continuous Transducer Low 15" (381 mm) Woofer, 3" (76 mm) Voice Coil Frequency Response 35–95 Hz (-10 dB) Maximum SPL 129 dB (@ 1 m) Connections (2) XLR+1/4" (6.35 mm) Inputs; (2) XLR Outputs; (1) IEC Power Cable Input Input Level Line +4 dBu (Nominal) External Controls Volume Control, Signal/Clip Limiter with LED, Polarity-Reverse Switch, High-Pass Filter Bypass Switch with LED, Extended Low-Frequency Switch with LED, Power Switch with LED Electronic Protections Electronic Clip, Thermal and Transducer Overdrive Protection Enclosure Internally Braced Plywood Cabinet; 35 mm Mounting Pole Socket on Top Panel Power Connection: Standard IEC Cable
Input Voltage: 110–120, 220–240 V AC; 50/60 Hz
Consumption: 450W
Fuse: T6.3AL AC250V (110–120 V) or T3.15AL AC250V (220–240 V)Dimensions (H x W x D) 24.8" (630 mm) x 21.34" (542 mm) x 20.3" (515 mm) Weight 62 lbs (28.2 kg) - Documents
Documents
- In The Box
In The Box
- (1) TS215S 15" Powered Subwoofer
- (1) Power Cable
- User Guide
- Safety & Warranty Manual
