Ashly Audio nXp3.02 2-Channel Network Power Amplifier 2 x 3000W @ 2 Ohms with Protea DSP

By Ashly Audio

Ashly Audio nXp3.02 2-Channel Network Power Amplifier 2 x 3000W @ 2 Ohms with Protea DSP

Name: Ashly Audio nXp3.02 2-Channel Network Power Amplifier 2 x 3000W @ 2 Ohms with Protea DSP
Brand: Ashly Audio
SKU: ASHLY-NXP3.02
Price: 3939 USD
Availability: InStock

Write a Review

Part #:

nXp3.02

Model #:

nXp3.02

Current Stock:

Availability: Usually arrives in 5-9 business days.

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Description

The Ashly nXp3.02 is a 2-channel rack mountable multi-mode amplifier capable of driving 2 ohm loads at full power. The nXp3.02 is designed to meet the most demanding live sound environments and fixed audio installations anywhere, performance venues, stadiums, arenas, convention centers as well as schools, storefronts, and worship spaces. The nXp is a Protea DSP amplifier that includes dynamics, gain, EQ, feedback suppression, FIR filters, matrix and auto-mixer, crossover, delay, and more. With a rated output power of 3,000W per channel at Low Z, 2,450W per channel in 70V mode, and 1,250W in 100V mode, you're sure to have ample power to meet the most demanding needs. The nXp3.02 is ethernet controllable using the Protea™ NE software and has a real-time clock with event scheduler. It also features Class-D switching amplifier technology, multiple internal power supplies, and a continuously variable cooling fan.

Features

Two channel high power, lightweight amplifier design
Individually configurable speaker outputs for Low-Z (to 2 Ohm), or High-Z (70V or 100V) via rear panel dip switches
Front panel power switch and level controls, defeatable
Front panel LEDs for temperature, current, signal, clip, mute, bridge mode, protect, sleep, and disable
Combo XLR - 1/4" jack and Euroblock connectors on all inputs
SpeakON® twist locking loudspeaker connectors for security, safety, and reliability
Back panel DIP switches per-channel for selection of hipass filter, limiter, input gain, and speaker output configuration
Remote DC level control per channel
Automatic selection of 110-120VAC or 220-240VAC operation, 50-60Hz, with detachable PowerCON® AC connector
Power-saving automatic sleep mode, less than 1W, defeatable
Continuously variable cooling fan
Extensive protection circuitry
Independent amplifier and power supply circuitry
Ethernet control and monitoring of amplifier functions, with front panel COM activity LED
iPad "Ashly Remote" application available for custom design of end-user wireless control interface
Serial data port for Ashly serial remote control devices such as the WR-5 or RD-8C
Optional RS-232 data converter for third-party controllers such as Crestron
Software defeatable power switch and level controls
Standby mode, 30% reduction from idle, triggered on or off by contact closure, software control, or event scheduler
Programmable power-on delay for Off-to-On or Sleep-to-On transitions
Preset recall via contact closure, software control, remote control, or event scheduler
Aux preamp outputs
Fault condition logic outputs
Optional Cobranet or Dante network audio and AES3 digital audio input with zero-latency pass-through
Protea DSP including dynamics, gain, EQ, feedback suppression, FIR filters, matrix and auto-mixer, crossover, delay, and more
Impedance monitoring of individual amplifier outputs for quick and easy diagnosis of potential speaker problems
iPad control of select DSP functions including gain, mute, matrix, A/B source select, PEQ filter level, and meters
Networkable remote gain and zone control using Ashly neWR-5 and FR-8/16
Five-year warranty

Specifications

Weight	28 lbs (12.7kg)
Dimensions (H x W x D)	3.5” (89 mm) x 19” (483 mm) x 16.84” (428 mm)
Shipping Dimension (H x W x D)	22" (559 mm) x 24.5" (622 mm) x 5.25" (133 mm)
