The AtlasIED C12BT60 12-inch 2-way coaxial speaker combines a 12-inch low-frequency driver with a 1-inch high-frequency driver and built-in 60W 70V/100V transformer. It delivers full-range music and voice reproduction with high power handling and smooth frequency response.

Description

AtlasIED C12BT60 12-Inch 2-Way Coaxial Speaker

The C12BT60 is a professional-grade 12-inch 2-way coaxial loudspeaker designed for high-quality music and voice reproduction in commercial and installed sound applications. It combines a 12-inch low-frequency driver with a 1-inch post-mounted high-frequency driver for clear, balanced full-range audio.

A curvilinear treated paper cone reduces harmonic distortion while maintaining durability under high output conditions. The built-in crossover network ensures proper frequency distribution between the low- and high-frequency sections, resulting in smooth, accurate sound reproduction.

The C12BT60 includes a factory-installed 60W 70V/100V line transformer, making it ideal for distributed audio systems. The transformer can also be bypassed for 8 ohm operation, providing installation flexibility across different system designs. It is recommended for use in enclosures of 2 cubic feet or larger, including AtlasIED Q Series models.

Features

12-inch 2-way coaxial loudspeaker for full-range audio
1-inch high-frequency driver with post-mounted design
60W 70V/100V factory-installed line transformer included
Transformer bypass option for 8 ohm operation
Built-in crossover network for smooth frequency transition
Curvilinear treated paper cone reduces harmonic distortion
Designed for music and voice reproduction applications
Recommended for enclosures 2 cu ft or larger
Compatible with AtlasIED Q Series enclosures and baffles
High power handling with professional sound quality

Specifications

Frequency Response (±10 dB)	40 Hz to 20 kHz
Frequency Response (±3 dB)	68 Hz to 15 kHz
Power Handling	100 Watts
Sensitivity 1W/1M	95 dB
Max. SPL @ 1M (Transformer Limited @ 60W)	113 dB
Crossover Frequency	2750 Hz
Dispersion Angle	90 Degrees
LF Transducer	Specifications
Basket Material	Cast Aluminum
Cone Material	Treated Paper
Surround Material & Dampening	Treated Accordian Cloth Edge
Voice Coil Diameter	1.5" (38 mm)
Magnet Weight	30 oz. (.85 kg)
HF Transducers	Specifications
Diaphragm Material	Treated Laminated Silk
Voice Coil Diameter	1" (25 mm)
Voice Coil Former Material	Aluminum
Voice Coil Material	Copper
Magnet Weight	10 oz. (283 g)
Top Plate Thickness	0.125" (3 mm)
Transformer	Specifications
Frequency Response	33 Hz to 21 kHz (±2 dB)
Primary Taps @ 70.7V	60,30,15,7.5
Maximum Insertion Loss	1 dB
Dimensions (Dia x D)	12.875" (327 mm) 4.1875" (106 mm)
Shipping Weight	5 lbs (2.27 kg)
