Atlas Sound ELI2K-B Compact Line Array Speaker System (Discontinued)

Part #:
ELI2K-B
Model #:
ELI2K-B
Availability: No Longer Available
Contact us for comparable solutions.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL

The Atlas Sound ELI2K-B Compact Line Array Speaker System is a highly intelligible, high efficiency speaker system that is ideally suited for use in speech and music reproduction applications such as small venues, houses of worship, small theaters, and schools.

Description

The Atlas A-Line ELI Line array speaker system is a highly intelligible, high efficiency speaker system that is ideally suited for use in speech and music reproduction applications such as small venues, houses of worship, small theaters, and schools. The system consists of two parts: the EL1503-B, which includes fifteen proprietary 3" drivers, and the ELW110, which has a single 10" low frequency driver. Both models utilize an optimally designed Baltic birch constructed enclosure. The ELW110A-B houses an integrated class D amplifier that includes onboard DSP. The ELW110A-B is designed to provide power to the ELW110X-B and the two EL1503-B arrays. The trim line, two cabinet design allows for sleek, clean looking set ups with minimal sightline interference. This kit includes everything needed to set up the system, including the power cable, speaker cables and pole.

Features

  • Fifteen Proprietary 3" Speakers
  • Sealed Baltic Birch Cabinet Design
  • Excellent Pattern Control to 300Hz
  • NL4 Speak-ON Connectors
  • I/O Powercon Connectors
  • Single 10" Low Frequency Driver
  • Integrated 200W RMS Class D Amplifier (A Version)
  • Finished in Heavy Duty Black Duracoat

Specifications

Midrange RMS Power 1000 Watts
Sensitivity 93 dB 1W/1m
High Frequency RMS Power 500 Watts
MAX SPL 107 dB
Amplifier Power 200 Watts
Frequency Response 50Hz - 150Hz
Horizontal Dispersion Omni
Dimensions (H x W x D)
EL1503-B Compact Line Array Speakers 49.6" (1260.5 mm) x 4.8" (122.3 mm) x 6.375" (162 mm)
ELW110A-B Powered Line Array Subwoofer 17.5" (445 mm) x 13" (330 mm) x 17.5" (445 mm)
ELW110X-B Passive Line Array Subwoofer 17.5" (445 mm) x 13" (330 mm) x 17.5" (445 mm)
Approx. Weight 121 lbs (54.88 kg)

DOCUMENTS

In The Box

  • (2) EL1503-B Compact Line Array Speakers
  • (1) ELW110A-B Powered Line Array Subwoofer
  • (1) ELW110X-B Passive Line Array Subwoofer
