The ATW-DA49 is a UHF (wide-band 440-900 MHz) active unity-gain diversity antenna distribution system that enables one pair of antennas to feed multiple wireless systems. Provides two "1-in, 4-out" RF channels; connects a pair of antennas to as many as four wireless receivers. Either passive or active antennas may be used. Both input jacks offer switchable +12V DC output on their center pins to operate Audio-Technica powered antennas or other in-line RF devices if desired. The unit features all-metal construction for extreme durability and protection from radio frequency interference.
The ATW-DA49 is designed to complement Audio-Technica 2000 and 3000 Series wireless systems. It is also suitable for many other wireless systems operating within the 440-900 MHz range.
Includes ten RF cables, front-mount antenna cables and connectors, four DC power cables, +12V DC desktop power supply with detachable IEC power cable and ATW-RM1 rack-mount hardware kit to permit attachment in a standard 19” rack space.
| Bandwidth | 440 - 900 MHz |
|---|---|
| Gain | 0 dB typical (within specified bandwidth) |
| Impedance | 50 ohms typical (within specifiedbandwidth) |
| Antenna Power (optional) | +12V DC, center positive,100 mA maximum per antenna input(2 total) |
| Termination Type | BNC Female (10 total) |
| Dimensions (Base Unit Only) | 8.27" (210.0 mm) W x1.79" (45.5 mm) H x 6.93" (176.0 mm) D |
| Weight | 2.0 lbs (0.9 kg) |
