Audio-Technica ES945W Omnidirectional Condenser Boundary Microphone
for Professional Recording and Teleconferencing ApplicationsThis low-profile omnidirectional condenser boundary microphone is designed for clear, highly intelligible sound reinforcement, professional recording and teleconferencing in table-, ceiling-, or panel-mount applications. The microphone is equipped with a self-contained power module with an XLRM-type output connector, eliminating the need for an external power module. The microphone offers unsurpassed immunity from radio frequency interference thanks to Audio-Technica's UniGuard® innovations. Protected by a rugged all-metal case with a two-layer steel mesh grille, the microphone has a 360° pickup angle, and is available in two colors: black (ES945) and white (ES945W).
- Features
Features
- Designed for surface-mount applications such as high-quality sound reinforcement, professional recording and teleconferencing
- Low-profile element provides uniform omnidirectional polar pattern with 360º acceptance angle
- Mounts unobtrusively in table-tops, ceilings and wall panels
- Self-contained power module with XLRM-type output connector
- Rugged all-metal case with a two-layer steel mesh grille
- Isolators provide mechanical dampening of mounting-surface vibration
- Requires 11V to 52V DC phantom power
- UniGuard® RFI-shielding technology offers outstanding rejection of radio frequency interference (RFI)
- Available in two colors: black (ES945) and white (ES945W)
- RoHS compliant—free from all substances specified in the EU directive on hazardous substances
- Specification
Element Fixed-Charge Back Plate Permanently Polarized Condenser Polar Pattern Omnidirectional Frequency Response 40 - 18,000 Hz Open Circuit Sensitivity -42 Db (7.9 Mv) Re 1v At 1 Pa Impedance 200 ohms Maximum Input Sound Level 142 Db Spl, 1 Khz At 1% T.H.D. Dynamic Range (Typical) 112 dB, 1 kHz at Max SPL Signal-To-Noise Ratio 64 dB, 1 kHz at 1 Pa Phantom Power Requirements 11-52V DC, 2 mA typical Output Connector Integral 3-pin XLRM-type Accessory Furnished One pair isolators Dimensions (Dia x L) 1.10" (28 mm) x 2.72" (69 mm) Weight 63 g (2.2 oz) - Documents
