The Audix ADS4 is a full range UHF antenna distribution system that allows up to 4 Audix wireless systems to run off a single pair of antennas. Multiple ADS4 systems can be cascaded in order to run as many as 16 wireless systems.

Description

The Audix ADS4 is a full range UHF antenna distribution system that allows up to 4 Audix wireless systems to run off a single pair of antennas. The ADS4 amplifies the RF signals internally in order to compensate for any loss that may result from splitting the signal. In addition, the ADS-4 has an internal switching power supply which eliminates the need for the individual DC power supplies normally needed for each receiver. Multiple ADS4 systems can be cascaded in order to run as many as 16 wireless systems.

Features

Power on/off switch with LED indicator
AC input
DC output jacks to power up to (4) RAD360 receivers
Ant. 2 input for rear mounting antenna
Ant. 1 input for rear mounting antenna
Ant. 2 output (4)
Ant. 1 output (4)
Antennas - front mounted

Specifications

Frequency Range	470-870 MHz
RF Output Level (Gain)	≥ 0.5-3 dB
Output Connection Isolation	≥ 25 dB
Impedance	50 Ohm
Input AC Voltage	90-260 V switching power
Output DC Voltage	12-18 V
Antenna Booster DC Voltage	12-18 V
Dimensions (H x W x D)	2" (45 mm) x 19" (480 mm) x 10" (250 mm)
Net Weight	4.73 lbs (2.15 kg)
