The Audix ADS48 is a wide range UHF antenna distribution system that combines up to four wireless systems to be able to run off a single pair of antennas and power supply. The ADS48 has an internal switching power supply which eliminates the need for the individual DC power supplies normally needed for each receiver. RF signals are internally amplified in order to compensate for any loss that may result from splitting the signal.

Description

Audix ADS48 Antenna Distribution System
for AP42/AP62 Two-Channel Microphone Systems

The Audix ADS48 is a wide range UHF antenna distribution system that combines up to four wireless systems to be able to run off a single pair of antennas and power supply. The ADS48 has an internal switching power supply which eliminates the need for the individual DC power supplies normally needed for each receiver. RF signals are internally amplified in order to compensate for any loss that may result from splitting the signal.

When used in conjunction with the AP42 or AP62 two-channel systems, the ADS48 is able to run 8 channels of wireless on a single pair of antennas and power supply taking up only 5 rack spaces.

Features

For use with Audix AP42 or AP62 two-channel microphone systems
Combines up to four (4) wireless systems to single pair of antennas and power supply
Internal switching power eliminates the need for individual power supplies for each receiver
Internally amplifies RF signals to compensate for splitting the signal

Specifications

Frequency Range	470 - 900 MHz
RF Output Level (Gain)	0 dB d + or - 3 dB
Input Impedance	50 Ohm
Output Impedance	50 Ohm
Power Voltage	100 - 240 V AC 50 / 60 Hz
Output DC Voltage	+12 V DC, 800 mA maximum
Antenna Input DC Voltage	8 V, 150 mA maximum
Dimensions (H x W x D)	2" (45 mm) x 19" (480 mm) x 10" (250 mm)
Net Weight	4.72 lbs (2.15 kg)

DOCUMENTS

In The Box

(1) ADS48 Antenna Distribution Unit with rack mount
(2) Antennas
(1) IEC power cable
(4) Power Jumper Cables to provide power to individual receivers
(8) BNC-to-BNC Coaxial Cables for pass-through connection for up to 4 additional receivers (single or dual)
(2) Coaxial cables for front mounting antennas
