Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.The DP8 is a high-performance 8-inch pendant loudspeaker designed for open architecture spaces or any location where a stylish pendant form factor is desired. Featuring high-power handling, higher sensitivity and realistic sound reproduction, the DP8 is the more focused big brother to the DP6. D SERIES pendant loudspeakers can be used in a wide variety of speech and music applications. They are equipped with a built-in autoformer, supporting low impedance or 70/100 volt operation. Uniform voicing means that the DP8 can be combined with other ceiling and surface mount models in the C or D SERIES family without compromising consistency from zone to zone. The genuine coaxial design uses separate magnets for the LF and HF drivers for reduced distortion and industry-leading sensitivity, thereby permitting 3 dB to 6 dB greater output level while requiring half the amplification power of competing products. An easy access selector switch is conveniently located on the face of the loudspeaker for selectable 8 ohms or 70/100-volt operation, while an integrated rear cover hides all wiring and hanging hardware for an aesthetically pleasing installation.
| Operating Range | 60 Hz - 22 kHz |
|---|---|
| Frequency Response | 80 Hz - 20 kHz (± 5 dB) |
| Max Input Ratings (8 ohm) | 150W continuous, 375W program 34.6 volts RMS, 69.3 volts momentary peak |
| Transformer Taps | 70V: 120W, 60W, 30W, 15W and low impedance 100V: 120W, 60W, 30W |
| Sensitivity (1W/1m) | 95 dB SPL (120 Hz to 12.5 kHz 1/3 octave bands) 94 dB SPL (250 Hz to 4 kHz speech range) |
| Maximum Output | 117 dB SPL / 123 dB SPL (peak 8 ohm) |
| Nominal Impedance | 8 ohms |
| Minimum Impedance | 5.6 ohms @ 200 Hz |
| Nominal Coverage | 100º conical (1 Hz to 6 kHz) 115º conical (500 Hz to 6 kHz) |
| Axial Q / DI | 6.4 / 8, 500 Hz to 6 kHz |
| Crossover Frequency | 1.3 kHz |
| Recommended High Pass Filter | 60 Hz / 24 dB octive |
| Drivers | LF 1 x 8" HF 1 x 1.25" exit compression driver |
| Driver Protection | Self-resetting solid state circuit breaker |
| Input Connection | Two 2-position Phoenix connectors |
| Controls | Front-face wattage / low impedance selector switch |
| Enclosure | UL 94V-0 rated ABS plastic, matte finish, paintable |
| Finish | Black or white |
| Grille | Powder coated steel with safety line, black or white finish, paintable |
| Baffle | Reflex loaded UL 94V-0 rated ABS |
| Safety Features | Included safety cable. Each cable has an SWL of 99 lbs (45 kg) |
| Dimensions (H x Dia) | 17.72" (450.1 mm) x 13.41" (340.5 mm) |
| Weight | 16.5 lbs (7.5 kg) |
| Shipping Weight | 23.2 lbs (10.5 kg) |
