- Description
Details
The Bosch LS1‑OC100E-1 Hemi-directional Loudspeaker is an easy to install, innovative loudspeaker which projects consistent and high quality sound, ensuring superb reproduction of background music and high speech intelligibility for paging or emergency calls. The speaker’s opening angle and high sound pressure level allows it to cover at least 600 m2, making it extremely suitable for indoor high-ceiling areas like warehouses, transport and exhibition halls, mega stores and swimming pools.
The LS1‑OC100E-1 is used in voice alarm systems and is compliant with emergency standards. The loudspeaker has built-in protection to ensure that a fire-damaged loudspeaker does not cause failure of the connected circuit. This ensures system integrity, meaning loudspeakers in other areas can still be used to inform people of the fire. The loudspeaker has ceramic terminal blocks, a thermal fuse and heat-resistant, high-temperature wiring.
The loudspeaker is made of high-impact ABS TSG, self-extinguishing according to class UL 94 V 0 and with the highest flame retardant rating (UL 94 5VA). The loudspeaker has a white and silver finish; the metal grille has a silver finish. This acoustically innovative loudspeaker accommodates 14 drivers in combination with
advanced positioning and filtering.- Features
Features
- For large area, high-ceiling applications
- Architecturally and acoustically innovative
- Hemi-directional pattern
- Optional bracket for fixed mounting
- Provision for internal mounting of the optional line/loudspeaker supervision board
- Specification
Maximum power 150 W Rated power 100 W (100 – 50 – 25 W) Sound pressure level at 100 W / 1 W (1 kHz, 1 m) 109 / 89 dB Sound pressure level at 100 W / 1 W (8 kHz, 1 m) 113 / 93 dB Opening angle at 1 kHz / 4 kHz (‑6 dB) 170º / 145º (horizontal)
170º / 170º (vertical)Effective frequency range (‑10 dB) 60 Hz to 17 kHz Rated voltage 100 V and 28.3 V Rated impedance 100 ohm and 8 ohm Connector Ceramic screw terminal Material ABS TSG Dimensions (H x Diameter) 31.50" (800 mm) x 16.74" (425 mm) Weight 63.93 lb (29 kg) - Reviews
