Bose Restaurant Sound System with Background Music and Paging for Indoor and Outdoor Coverage (Up to 4,500 SF)

Inside the Design

This 70V restaurant sound system delivers high-quality audio for both indoor and outdoor dining areas, covering approximately 4,500 sq. ft. and expandable for larger spaces. Designed for hospitality environments, it provides background music and paging that enhances your customers’ dining experience. You can connect a variety of audio sources, including Bluetooth devices, music streaming services, MP3 players, TV audio, and multi-disc CD players. Additional speakers can be added to extend coverage while maintaining separate zones for music and paging, ensuring even, unobtrusive sound throughout your venue.

Sound System Features:

• Easy-to-install 70V commercial sound system with Bose professional high-performance products
• Weather-resistant speakers suitable for year-round indoor and outdoor use, UV fade resistant
• Up to 4,500 sq. ft. of coverage, expandable for larger areas and outdoor seating
• Bose PowerSpace amplifier enhances any premium commercial sound installation with clean, reliable power
• Paging capable by adding a microphone (sold separately) or connecting to your telephone system
• ControlSpace CSP-1248 features integrated browser-based control software for simplified hardware management
• Lifetime technical support ensures easy operation and long-term reliability

About the System Components

Bose FreeSpace FS2C Ceiling Speakers

The system includes eight Bose FreeSpace FS2C 2.5" ceiling loudspeakers with adjustable tile bridges. These speakers deliver clear, full-range sound for indoor areas, offering durable, high-performance audio. The adjustable tile bridges make installation simple and ensure optimal positioning for even coverage throughout your dining spaces.

Bose FreeSpace FS4SE Surface-Mount Outdoor Speakers

Four Bose FreeSpace FS4SE surface-mount outdoor-rated speakers provide reliable audio coverage for patios and outdoor dining areas. Built to withstand weather and UV exposure, these speakers maintain consistent, high-quality sound, making them ideal for year-round outdoor use.

Bose PowerSpace P4300A Amplifier

The Bose PowerSpace P4300A is a 4-channel, 300W versatile amplifier with Amplink. It delivers clean, reliable power to all connected speakers, supporting large and expanded sound zones while maintaining clarity and consistent performance for both music and paging applications.

ControlSpace CSP-1248 Commercial Sound Processor

The ControlSpace CSP-1248 provides browser-based control software for simplified configuration and management of the sound system. It allows precise audio adjustments for multiple zones, making it easy to customize the audio environment for different areas of your restaurant or patio.

Bose FreeSpace FS2C 2.25" Ceiling Loudspeakers:

• Full-range 2.25-inch transducer, low-frequency range down to 83 Hz, 16-ohm, and 70/100V operation
• Front baffle-mounted tap settings and front-baffle audio connections
• Pick your power — FS2 models feature a 2.25-inch full-range transducer, low frequency down to 83 Hz, 16-ohm and 70/100V operation
• Maintain consistent tonal quality with shared voicing across all FS models
• Hear the best of both — music and voice — with transducers that offer clear voice reproduction and smooth response for background music
• Bring quality sound to more places
• Customize systems with confidence using in-ceiling, surface-mount, and pendant-mount options, allowing for tailored mix-and-match installations. DesignMax subwoofers and larger models can expand your system design options even further
• Blend with more room designs with updated enclosures — available in black and white — that pair modern aesthetics with practical features, including removable logos
• Tackle site-specific challenges with the support of a full suite of accessories, designed to handle a wide range of applications and mounting options
• Install with ease — all models feature Euroblock inputs and front-baffle input location on in-ceiling models
• Support public safety — all models are UL 1480 ULC-S541-listed for use in fire alarm and signaling systems in life safety applications



Bose FreeSpace FS4SE 4.5" Indoor Outdoor Surface-Mount Loudspeakers:

• Full-range 4.5-inch transducer, low-frequency range down to 70 Hz, 8-ohm and 70/100V operation
• Handles the weather, designed for outdoor wet installation
• Maintain consistent tonal quality with shared voicing across all FS models
• Hear the best of both — music and voice — with transducers that offer clear voice reproduction and smooth response for background music
• Blend with more room designs with updated enclosures — available in black and white — that pair modern aesthetics with practical features, including removable logos
• Tackle site-specific challenges with the support of a full suite of accessories, designed to handle a wide range of applications and mounting options
• Install with ease — all models feature Euroblock inputs and front-baffle input location on in-ceiling models
• Support public safety — all models are UL 1480 ULC-S541-listed for use in fire alarm and signaling systems in life safety applications



Bose 360P Series II Environmental Loudspeakers:

• Full-range environmental loudspeaker with one downward firing 4.5" (114 mm) advance composite environmental full-range driver for in-ground or above-ground mounting
• Domed port grille reflects sound into the listening area for clear, consistent performance
• Cabinet shape acts as acoustic diffuser directing mid- and high-frequency energy out towards listeners. Base of loudspeaker acts as a tuned, multi-chambered ported enclosure
• Multi-tap line transformer provides easy-to-change tap settings
• Tamper-resistant design
• Internal speaker protection circuit safeguards drivers



Bose PowerSpace P4300A 4-Channel 300W Versatile Power Amplifier with Amplink:

• 300 watts per channel and works seamlessly with Bose loudspeakers, DSPs, and controls to create complete commercial sound systems
• Bose AmpLink input for simplified multichannel digital audio connection to compatible DSPs, reducing terminations and related points of failure
• Load-independent outputs deliver full channel power to either low-impedance loads (4-8 Ω) or high-impedance (70/100V) loads without bridging
• I-Share outputs deliver 2x power level into low-impedance (2-8 Ω) or high-impedance (70/100V) loads by combining the current of both channels
• Auto-standby mode saves power when audio signal falls below a set threshold after 20 minutes, then wakes when audio returns



Bose ControlSpace CSP-1248 Commercial Sound Processor:

• Bose AmpLink, balanced analog I/O, RCA inputs, 8 GPIs, 1 GPO, a mute contact, RS-232 serial, and Ethernet network
• Integrated browser-based control software for direct and simplified access to hardware configuration
• With the accessory AVM-1 sense microphone, AutoVolume compensation continually adapts zone output level based on ambient room noise
• SmartBass dynamic equalization enhances low-frequency output of select loudspeakers
• Opti-voice® paging provides a smooth transition between the music and page signals
• Opti-source® level management monitors and adjusts the input level of up to four sources

• (8) Bose FreeSpace FS2C 2.5" Ceiling Loudspeakers - White
• (2) Bose FreeSpace FS2C Tile Bridges, Adjustable (6-Pack)
• (4) Bose FreeSpace FS4SE 4.5" Outdoor Rated Surface-Mount Loudspeakers - Black
• (2) Bose FreeSpace 360P Series II Environmental Loudspeakers
• (1) Bose PowerSpace P4300A 4-Channel 300W Versatile Power Amplifier with Amplink
• (1) Bose ControlSpace CSP-1248 Commercial Sound Processor
• (1) Hosa CMR-206 Stereo Breakout Audio Cable
• (1,000) West Penn 225 16/2 Non-Plenum Audio Speaker Wire
