Cambridge Qt X 800D Multi-Zone Sound Masking Generator with Dante
The Cambridge Qt® X 800D control module is a sound masking generator, controller, third-octave band equalizer and amplifier, with two auxiliary audio inputs to allow for distribution of audio from paging controllers and/or (background) music players. The Qt X 800D controls sound masking speakers/emitters in both direct-field and indirect (in-plenum) installations—or a mix of both. Each of the eight amplified output speakers/emitters can be independently adjusted for masking and aux audio levels and spectra. Both models feature full compatibility with Biamp's SageVue™ system management software and can participate in larger Qt X systems. When multiple Qt X controllers are included in a single system audio inputs can be shared across all controllers via Dante.
- Features
Features
- Compatible with DynasoundPro™ loudspeakers
- Supports up to eight zones
- Dante media network
- Two audio inputs for paging and music
- Contact closure integrates with fire alarm systems
- Front panel with LCD
- Front panel lock (via software control)
- Auto-ramping
- Event scheduling
- Adjustable equalizer for masking and audio inputs
- Eight included non-correlated sound masking audio sources (one for each output)
- PoE+ Powered with optional 48V dc input
- Built-in clock with system NTP support
- Plenum mount bracket included, optional wall or rack mount bracket also available
- Dual network ports (media / control)
- Third-party control API/Ethernet
- CE marked, ETL listed, and RoHS compliant
- Covered by Biamp Systems' five-year warranty
- Manufactured in the U.S.A.
- TAA compliant
- GSA eligible
- Meets UL 2043 requirements for installation in air handling spaces
- Specification
Operating Voltage 100-240VAC 50/60Hz Number of Non-Correlated Masking Sources 8 Output Connections (8) Captive Screw Terminal Audio Inputs Input Connector Type: Captive Screw Terminal
Number of Inputs: 2 (Stereo or Mono)Audio Input Level +24dBu (12.3VRMS max) Equalization Sound Masking (100Hz – 10kHz): ISO 1/3 Octave Bands
Active (125Hz – 8kHz): ISO 1/1 Octave BandDimensions (H x W x D) 3.5" (89 mm) x 11" (279 mm) x 3.8" (96.5 mm) Weight 1.5 lbs (0.68 kg) - Documents
