Community IS6-218WR Medium Power Dual 18-inch Weather-Resistant Subwoofer
I SERIES Subwoofer 600 weather-resistant loudspeakers provide excellent acoustic performance, modular flexibility and elegant aesthetics for modern performance venues. Designed to support the goals of systems integrators and consultants both acoustically and mechanically, I SERIES Subwoofers provide a broad range of sizes and capabilities that can be specifically matched to the needs of any modern venue.
Each cabinet was carefully designed to provide matching face widths and suspension point locations for seamless integration into flown arrays with I SERIES full-range models when additional LF extension is needed.
The IS6-218WR is a compact, direct radiating subwoofer with large, balanced ports that provide optimal enclosure tuning and even air pressure distribution to the driver cone, reducing distortion and extending system longevity. Drivers are loaded into individual air volumes within the enclosure, isolating their performance from one another. This arrangement not only provides additional protection to drivers in case of failures but also allows the designer to implement directional subwoofer techniques, like steered end-fire arrays and cardioid patterns, within a single enclosure when using any I SERIES dual driver subwoofer model.
| Operating Mode | Single or Dual Amp |
|---|---|
| Operating Environment | Indoor or Weather-Resistant Outdoor |
| Operating Range | 32 Hz to 145 Hz |
| Transducers | 2 x 18" (457mm) double-treated cones with 4" (102mm) inner/outer wound voice coil, ferrite construction |
| Nominal Sensitivity | @ 1W: Half Space - 107 dB, Whole Space - 101 dB @ 2.83V: Half Space - 110 dB, Whole Space - 104 dB |
| Nominal Maximum SPL | Peak: Half Space - 144 dB, Whole Space - 138 dB Continuous: Half Space - 138 dB, Whole Space - 132 dB |
| Input Connection | (2) 4 position screw terminal blocks |
| Mounting Points | (23) M10 threaded rigging points |
| Environmental | Outdoor: IP55W per IEC 60529 , MIL-STD-810G |
| Accessories | Rigging kits include: BFR22: BalancePoint™ Fly Rails; IAF55: Isometric Array Frame; VAB-BFR38: Sub Above Vert. Array; HAB3: Sub/Dual 2-Way Horiz. Array; HVS3: Multiple Horiz./Vert. Array Kits with Sub Behind Array Options; TPK: Tight Pack Kit; IUB1153WRG: Reinforced 304SS U-Bracket (WR models only) |
| Dimensions (H x W x D) | 39" (991 mm) x 22.1" (561 mm) x 28.89" (734 mm) |
| Net Weight | 170 lbs (77.1 kg) |
| Shipping Weight | 190 lbs (86.2 kg) |
