Community R2-52MAX 3-Way High Output 50° x 20° Weather Resistant Loudspeaker
The R2-52MAX is a three-way, full-range loudspeaker system designed to provide "No Compromises" premium music reproduction at very high output levels, and also improves the legendary R2 voice projection and intelligibility capabilities. It is designed with the same materials and construction as the standard R2 for extreme weather resistance, and can withstand long-term exposure to tough environmental conditions.
The R2-MAX is constructed with premium components in a biamp format to maximally optimize its performance. It uses a very high sensitivity 1" HF compression driver that provides extended HF response and a balanced frequency response with the rest of the system. Operated with a high crossover frequency, the HF driver maintains very high headroom, delivering effortless performance. The dual, high power 12" LF drivers feature an aluminum demodulation ring for very clean, low distortion performance. The dual midrange drivers are higher performance versions of the legendary low compression ratio M200 2" exit compression driver, achieving 3dB greater output with extremely low distortion. The passive MF/HF horn signal aligns the drivers for the best possible music and speech performance. The result is an excellent loudspeaker system that is capable of exceeding expectations in any application.
| Operating Mode | Biamp with DSP (Passive MF/HF) |
|---|---|
| Operating Environment | Indoor / Continuous outdoor direct exposure |
| Operating Range | 71 Hz to 19.5 kHz |
| Nominal Beamwidth (H x V) | 50°x 20° |
| Transducers | LF –2 x 12" inherently weather-resistant cones with 3" voice coil, neodymium motor and aluminum demodulation ring MF - 2 x 2" exit, M200HP compression, 3.5" diaphragm, 2.2" Voice coil, high temp non-metallic diaphragm HF – 1 x 1" exit compression, 1.7" voice coil, demodulation ring, ketone polymer diaphragm |
| Input Connection | 2 x 12' (3.6 m) 16-2 SJOW cables |
| Mounting Provisions | (5) 1/2"-13 threaded rigging points, Steel zinc-rich epoxy dual-layer powder-coated bracket with (2) aluminum aiming straps to secure angle |
| Environmental | IP55 per IEC 60529, conforms with MIL-STD-810G |
| Dimensions (H x W x D) | 24.75" (629 mm) x 24.75" (629 mm) x 30.75" (781 mm) |
| Weight | 99 lbs (44.9 kg) loudspeaker only 122 lbs (55.3 kg) loudspeaker and yoke |
| Shipping Weight | 132 lbs (59.9 kg) |
