The V2-28WT in white is a high-performance dual 8" two-way full-range loudspeaker designed for distributed and delay sound systems. With a built-in 200W autoformer for 70/100V applications, it is ideal for cafes, restaurants, shopping centers, airports, and other commercial environments. Its dual cone drivers provide extended low-frequency and midrange output compared to the V2-8, delivering full, high-fidelity sound in a compact enclosure. When paired with a subwoofer like the V2-212S, the V2-28WT produces broad-spectrum sound that belies its modest size.
Perfect for ancillary delay applications in auditoria, theaters, and houses of worship, the V2-28WT ensures consistent sound levels from front to rear of the room. Its 90° H x 70° V dispersion pattern, frequency-shaded woofers, and constant-directivity rotatable square horn deliver smooth, controlled coverage. The user-rotatable horn allows optimal performance in vertical or horizontal mounting, and the included yoke bracket with 10° and 20° vertical standoffs provides flexible wall or ceiling installation options.
Built for reliability, the V2-28WT features Dyna-Tech driver protection circuitry, ferrofluid-treated HF drivers, and Carbon Ring Cone Technology for increased LF piston area and excursion capability. With terminal strip and NL4-compatible connectors, multiple mounting options, and a durable white finish, this loudspeaker is ideal for distributed systems, delay fill, or supplemental PA in a variety of venues. Fully compatible with Community ALC404D controllers, higher-power ALC models may also be safely used.
| Operating Range | 60 Hz to 18 kHz (-10 dB) |
|---|---|
| Frequency Response | 90 Hz to 16 kHz (±3 dB) |
| Max Input Ratings | 300W continuous, 750W program 34.6 volts RMS, 69.2 volts momentary peak |
| Sensitivity (1W/1m) | 94 dB (100 Hz to 12.5 kHz) free space |
| Maximum Output | 119 dB SPL / 125 dB SPL (peak) |
| Nominal Impedance | 4 ohms |
| Minimum Impedance | 3.4 ohms @ 200 Hz |
| Nominal –6 dB Beamwidth | 90° H x 70° V (in vertical position) |
| Crossover Frequency | 1.3 kHz |
| Recommended Signal Processing | 70 Hz, 24 dB/octave Butterworth high pass filter |
| Drivers | LF 2 x 8" cone HF 1 x 1" |
| Driver Protection | DYNA-TECH protection circuitry |
| Input Connection | NL4-compatible locking connector with terminal strip in parallel |
| Enclosure | Trapezoidal (22.5° included angle) 18 mm, 11-ply cross-laminated birch |
| Mounting/Rigging Provisions | 9 x M6 threaded rigging fittings 4 x M6 threaded fittings for V-HSS 4 x M8 for third-party suspension products |
| Finish | Catalyzed polyester two-part paint, white |
| Grille | Powder coated steel, white finish |
| Dimensions (H x W x D) | 25.5" (649 mm) x 11.3" (287 mm) x 11.7" (298 mm) |
| Weight (incl. Bracket) | 38.7 lbs (17.7 kg) |
| Shipping Weight | 48.7 lbs (22.09 kg) |
