With comprehensive in/out connections and the latest Bluetooth 4.0 wireless technology, the DN-700AVP is the ideal surround preamp for any commercial audio-video system. Featuring six HDMI inputs, component/composite ins/outs, XLR balanced and RCA unbalanced 7.1 pre-outs and RS-232C and IP control, the 700AV is uniquely capable of handling virtually any installation requirement.
The unit is compatible with many of today's multi-channel formats, including TrueHD/Dolby Digital Plus/Dolby Digital/ DTS-HD/MasterAudio/DTS ES. Plus, it’s HDCP-compatible and has network streaming via DLNA.
With a rackmount chassis, the DN-700AVP was designed with the contractor in mind. A balanced XLR stereo input rounds-off the feature set aimed at the professional installer.
| Bluetooth Specs | Version: 4.0 Profile: A2DP, AVRCP Maximum Transmission Power: -6dB ± 4dB, Class 2 Frequency: 2.4GHz - 2.48 GHz |
|---|---|
| FM Tuner | Frequency Range: 87.5 MHz - 108 MHz |
| USB | File System: FAT 16/32 Media Type: USB Flash Drive |
| Audio Specs | Preamp Outputs: 7.1 Surround Sound Level: -10dB or +4db Frequency Response: 10kHz - 20kHz ± 1.0dB Dynamic Range: 10kHz - 20kHz, A-weighted >90dB Signal-to-Noise: 1 kHz, 0 dB, A-weighted >90dB Distortion: |
| Supported Surround Formats | Dolby TrueHD, Dolby Digital Plus, Dolby Digital, DTS-HD Master Audio, DTS ES |
| Supported File Types | WMA, MP3, WAV, MPEG-4 AAC, and FLAC files |
| Analog Input | Unbalanced RCA: Nominal Level: -10 dBV (at full scale: -16 dB) Minimum Input Level: -19 dBv or higher Input Impedance: 47 kΩ ± 10%, Unbalanced |
| Digital Inputs | Coaxial: RCA (IEC-60958 Type II) Optical: Toslink (IEC-60958 Type II) |
| Composite Video | Input/Output Level: 1V/p-p Impedance: 75 Ω Frequency Response: 5 Hz - 10 MHz |
| Component Video | Input Level: Y signal, 1Vp-p Pb/Cb signal, 0.7Vp-p Pr/Cr signal, 0.7Vp-p |
| Impedance | Y signal, 75 Ω PB/CB signal, 75 Ω PR/CR signal, 75 Ω |
| Frequency Response | 5 Hz – 60 MHz |
| HDMI | Version 1.4b (3D and ARC supported) |
| Power | Connection: IEC Input Voltage: 100 - 120V / 220-240V Consumption: 30W Operating Temperature: 41° F - 113° F Operating Humidity: 25 - 85%, non-condensing |
| Dimensions (H x W x D) | 6.93" (176 mm) x 19" (483 mm) x 13.66" (347 mm) |
| Weight | 19.1 lbs (8.66 kg) |
