The DynasoundPro DS1626 sound masking amplifiers are well suited for traditional 70 volt systems and smaller installations. It is used when with the DS3008 or DS3002 DynasoundPro sound masking generators.
- Features
Features
- Two or four channel lightweight design
- Universal input switch mode power supply with active power factor correction (PFC)
- Individually configurable speaker outputs for low-impedance (2, 4, or 8 Ohm), or 25V, 70V, or 100V constant voltage
- Power-saving automatic sleep mode, less than 1W, defeatable
- Rear panel DIP switch per channel for selection of hi-pass filter, limiter, input gain, and speaker output mode
- Front panel power switch, defeatable
- Rear panel level controls, defeatable
- Front panel LEDs for temperature, current, signal, clip, mute, bridge mode, protect, sleep, and power switch disable
- Euroblock connectors on all inputs and outputs
- Remote DC level control per channel
- Detachable AC mains line-cord connector with universal 120-240VAC range
- Continuously variable cooling fan
- Amplifier protection: Shorted output power limiting, over-temperature, power supply fault, DC-output, mains fuses & inrush current limiting
- Specification
Voltage Gain Selectable at 26dB, 32dB, 38dB, or 1.4V Damping Factor >250 (8 Ohm load <1kHz) Input High Pass Filter 80Hz 2nd Order Distortion (SMPTE, typical) <0.5% Distortion (THD-N, typical) <0.5% (8 Ohms, 10dB Below Rated Power, 20Hz–20kHz) Channel Separation -75dB (dB From Full Output, 1kHz) Signal-to-Noise (unweighted) 20Hz-20kHz, Gain@26dB >99dB (All 150x Models)
>96dB (All 75x Models)Frequency Response 20Hz-20kHz, +/-0.05dB Balanced Input Connector Euroblock 3.5mm Input Impedance 10k Ohms Maximum Input Level +21dBu Speaker Output Connector Euroblock 7.62mm Remote DC Level Control Euroblock 3.5mm – Gnd, CV, V+ Per Input Attenuators (per channel) Rear Panel, Fully Off = Mute Amplifier Protection Shorted Output Power Limiting, Over-Temperature, DC-Output, Power-Supply Fault, Mains-Fuses & inrush-Current Limiting Cooling Continuously Variable Temperature Controlled Fan Environmental 32°F-120°F, (0°C-49°C) non-condensing Dimension (H x W x D) 1.75" (44.45 mm) x 19" (482.6 mm) x 14.54" (369.31 mm) Weight 12.1 lbs (5.5 kg) - Documents
