The DSP (Digital Signal Processing) menus offer extensive configurations, crossovers, selective voicing, protection limiters, EQ modes, and a lockout mode prevents casual changes to the system. Loudspeaker system performance is optimized via an LCD screen. The front LED indicates power or can be configured to indicate limit.
EV-patented SST (Signal Synchronized Transducers) waveguide design provides uniform coverage and directivity. Waveguides are optimized using advanced simulation software and propriety algorithms for precise control and lowest distortion. ETX EV designed and manufactured transducers include SMX woofer technology using composite cone materials, flux stabilizing rings, and thermal management. This transducer yields lower distortion, smooth response and high SPL. The high-efficiency DH3-B compression driver has a convex diaphragm driving a coherent phase device extending frequency response to 20 kHz. EV's FIR-Drive technology utilized the latest FIR (Finite Impulse Response) filter technology to optimize transducer linearity and advanced limiter algorithms for independent peak and thermal transducer protection. The enclosure is constructed out of 18- mm, 13-ply birch plywood finished with EVCoat. ETX combines EV-engineered intelligent DSP, high-powered amplifiers and high-efficiency transducers to deliver that legendary EV sound and performance.
| Frequency Response (-3 dB) | 48 Hz – 20 kHz |
|---|---|
| Frequency Range (-10 dB) | 40 Hz – 20 kHz |
| Maximum SPL | 135 dB peak |
| Coverage (H x V) | 90° x 60° |
| Power Rating | 2000W |
| LF Transducer | SMX2150 15" (380 mm) |
| HF Transducer | DH3-B 1.25" titanium compression driver |
| Crossover Frequency | 1500 Hz |
| Connectors | (2) XLR/TRS combo jack and (1) XLR link output |
| Enclosure | 18 mm, 13-ply birch plywood withEVCoat |
| Grille | 16AWG steel with powdercoat |
| Suspension | (8) M10 suspension points |
| Power Consumption | 100 – 240 V~, 50 – 60 Hz, 1.6 –0.8 A3 |
| Dimensions (H x W x D) | 27" (691 mm) x 17" (431 mm) x 18" (447 mm) |
| Net Weight | 61.1 lbs (27.7 kg) |
| Shipping Weight | 69.5 lbs (31.5 kg) |
