The DSP (Digital Signal Processing) menus offer extensive configurations, crossovers, selective voicing, protection limiters, EQ modes, and a lockout mode prevents casual changes to the system. Loudspeaker system performance is optimized via an LCD screen. The front LED indicates power or can be configured to indicate limit.
ETX-35P features three (3) high-sensitivity transducers, for high output sound which is optimized for precise coverage and low distortion. ETX EV designed and manufactured transducers include SMX woofer technology using composite cone materials, flux stabilizing rings, and thermal management. This transducer yields lower distortion, smooth response and high SPL. The high-efficiency DH3-B compression driver has a convex diaphragm driving a coherent phase device extending frequency response to 20 kHz. EV’s FIR-Drive technology utilized the latest FIR (Finite Impulse Response) filter technology to optimize transducer linearity and advanced limiter algorithms for independent peak and thermal transducer protection. The enclosure is constructed out of 18-mm, 13-ply birch plywood finished with EVCoat.
| Frequency Response (-3 dB) | 48 Hz – 20 kHz |
|---|---|
| Frequency Range (-10 dB) | 38 Hz – 20 kHz |
| Maximum SPL | 136 dB peak |
| Coverage (H x V) | 60° x 40° |
| Power Rating | 2000W |
| LF Transducer | SMX2151 15" (380 mm) |
| MB Transducer | EVS-6C 6.5" mid-bass driver |
| HF Transducer | DH3-B 1.25-in titanium compression driver |
| Crossover Frequency | 700 Hz, 2900 Hz |
| Connectors | (2) XLR/TRS combo jack and (1) XLR link output |
| Enclosure | 18 mm, 13-ply birch plywood with EVCoat |
| Grille | 16AWG steel with powdercoat |
| Suspension | (8) M10 suspension points |
| Power Consumption | 100 – 240 V~, 50 – 60 Hz, 1.6 – 0.8A3 |
| Dimensions (H x W x D) | 40" (1023 mm) x 18" (469 mm) x 17" (426 mm) |
| Net Weight | 84.2 lbs (38.2 kg) |
| Shipping Weight | 94.4 lbs (42.8 kg) |
