The JBL PRX710 is a 10" compact and ultra-lightweight speaker designed to deliver maximum performance for its weight and size.

Description

The JBL PRX710 is the most compact and versatile speaker in the PRX700 Series. Designed to deliver maximum performance for its weight and size as a front of house main PA. Two user selectable EQ settings are provided to optimize the system for either application. With a dual socket pole mount the PRX710 is a perfect match with a PRX700 Series subwoofer, offering a high performance self-powered sub/sat system.

The PRX710 is the next step in the highly successful PRX Series and introduces the ﬁrst use of JBL’s patented Differential Drive® Technology with ferrite drivers. Differential Drive Technology incorporates lower mass in the ferrite magnet for reduced weight while maximizing power amp efficiency for greater heat dissipation and increased power handling. Powering the PRX710 is a 1500 Watt high performance, exceptionally low distortion bi-ampliﬁcation system engineered to deliver clean power with maximum headroom to efficiently deliver smooth high frequencies and rich, deep bass response even at very high sound power levels.

Compact and ultra-lightweight, the PRX710 uses JBL’s tour tested technology throughout so you can trust it to deliver a lifetime of reliable performance.

Features

133 dB peak SPL
10" Differential Drive® low-frequency driver for low-distortion and higher SPL
1.5" diameter next generation JBL neodymium compression driver
JBL designed waveguide for accurate coverage
Efficient Class-D amplifier technology
Normal and Boost user selectable EQ presets
DSP input section, crossover, dynamic limiting, component optimization, selectable system EQ
Line level and direct microphone input capability
Professional XLR-1/4" combination inputs, RCA inputs, and XLR loop-through
Integrated 36 mm pole mount socket
Integrated handle with injection molded backing cup for easy transport
Integrated M10 suspension points for easy setup
Lightweight poplar plywood cabinets made structurally sound with tongue and groove joints and protected by JBL’s tour proven DuraFlex™finish
Cloth backed, dent-resistant 16 gauge steel grilles

Specifications

Power Rating	1500 W
Frequency Range (-10 dB)	Normal: 50 Hz – 19.6kHz Boost: 42.9 Hz – 20kHz
Frequency Response (±3 dB)	Normal: 63.5 Hz – 18.5kHz Boost: 53 Hz – 18.6kHz
Coverage Pattern	100° x 60° nominal
Directivity Index (DI)	9 dB
Directivity Factor (Q)	8
Crossover Frequency	1.9 kHz
Maximum SPL	133 dB
Dynamic Control (Input)	dbx Type IV™ limiter circuit
Input Impedance	20K Ohms (balanced), 10K Ohms (unbalanced)
LF Driver	1 x JBL M110-4 250mm (10 in) woofer
HF Driver	1 x JBL 2408H-2 37.5 mm (1.5") annular polymer diaphragm, neodymium compression driver
Enclosure	Trapezoidal, 18 mm, plywood
Suspension / Mounting	Single 36 mm pole socket, 8 x M10 Suspension Points, 1 x M10 pull back point
Transport	1 x integrated handle with injection molded backing cup
Finish	Obsidian DuraFlex™ finish
Grille	Powder coated, Obsidian, 16 gauge perforated steel with acoustical transparent black cloth backing
Input Connectors	2 x Balanced XLR / 1/4 inch input, 2 x unbalanced RCA input
Output Connectors	1 male XLR balanced output
Dimensions	19.63" (499 mm) x 13.21" (336 mm) x 12.69" (322 mm)
Net Weight	36 lbs (16.4 kg)
