Listen Tech D14-2 D Series Multiloop Driver (Discontinued)

The D14-2 hearing loop amplifier is a 14 Amp dual output class 'D' driver; meaning a 60%+ increase in energy efficiency over existing solutions. Both drivers feature capacitive touch front panels with intuitive menus, built-in test signals, and are fully networkable with a Wi-Fi accessible standard browser-based control panel for remote set-up, monitoring, and email alerts.

The D14-2 features 14 Amps per loop output plus ample voltage headroom, making it the most flexible solution on the market, suitable for a large range of applications. The added power of the D14-2 provides a solution for installations in environments containing very high levels of metal, previously not possible without the use of combiners.

In another first for high-power Class D Induction Loop Drivers, installation can be performed with total confidence, as unique multi-stage filtering ensures compatibility with both other system equipment and global EMC regulations. The D14-2 also boasts Dual Slope Metal Loss Control that caters to a wide range of metal loss frequency characteristics.

• Drives 2 output channels at 14ARMS each, featuring accurate and stable 90° phase shift
• Networkable with remote browser interface
• Digital display and intuitive 'touch' menu system
• 3 modes; Main, Status, and Quick
• Highly energy efficient Class-D amplifier with low heat dissipation
• Up to 2 x 1,300m2 (13993 sq. ft.) Perimeter Loops area coverage
• Up to 3,300 m2 (35,520 sq. ft.) MultiLoop™ Low Loss area coverage
• Compact 1U rack-mount unit with internal transformer for simple rack installation
• Optimized for speech frequencies with unmatched intelligibility and capable of high-quality musical reproduction
• AGC and Dual Slope MLC
• Active status monitoring and remote fault reporting via email
• Data compliant with: IEC 62489-1 Standard

Spec Sheet

Manual

• (1) D14-2 D Series MultiLoop Driver (14 Amps x 2)
• (1) 1U 19" Rack Mount (Brackets Included)
• (1) Handbook and Installation Instructions
• (1) T-Coil Loop System Present Sign (Deaf Logo)
• (2) Neutrik NL4 Output Connectors for Each Output
• (1) Region Specific IEC Power Cable
• (1) Status and DC Connectors
