Mackie Big Knob Studio Command System (Discontinued)

Part #:
0008466-00
Model #:
Big Knob
Availability: No Longer Available
Contact us for comparable solutions.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL

The Mackie Big Knob is a simple yet powerful desktop audio control center that lets musicians and engineers get right to the business of making music.

Description

The Big Knob is a simple yet powerful desktop audio control center that lets musicians and engineers get right to the business of making music in four major ways: Level Control, Studio Monitor Selection, Input Source Selection and Talkback & Headphone Control. Using a big, convenient volume knob, Big Knob lets you adjust volume levels the way our ancient audio ancestors (Analogus Engineerus) did - with a simple, intuitive knob, not with a mouse and screen. The end result is a higher degree of precision and much quicker level adjustments. When it comes to mixing, pros know it’s best to get a second, and third, opinion. So Big Knob lets you quickly switch between 3 pairs of studio monitors, or 2 studio monitors and a subwoofer, or studio monitors and a home stereo, or any other combination of powered speakers.

On the input side, Big Knob lets you connect up to 4 stereo input sources at once. This means you can simultaneously connect to your computer/DAW outputs, CD player, cassette deck and even a turntable using the premium onboard RIAA preamp. You can even connect keyboards, guitars, drum machines, samplers - anything you’d like to hear - through your monitors. This makes Big Knob great for comparing your mixes-in-progress to your favorite CDs, for archiving your old LPs, jamming along to your favorite tune, and lots more. Because Big Knob plays a crucial link between recording output(s) and studio monitors, we placed the utmost importance on pristine, no-compromise sound quality. For this reason, Big Knob features ultra low-noise op amps, extremely low-tolerance components and state-of-the-art surface mount technology. All of this ensures superb sound in critical listening environments and long-term reliability - even under daily, and nightly, studio use. With its built-in Talkback mic and spring-loaded activation switches, Big Knob lets you quickly communicate with musicians in both the studio and tracking room - no more hand signals through the glass!

Features

  • Tabletop control room monitoring source and speaker selector
  • Large, robust, high-precision volume control knob
  • Monitor A, B and C selector switches with LED's and connectors for 3 separate pairs of powered studio monitors, subwoofers or power amplifiers
  • Dedicated trim controls for all Monitor output connector sections
  • Dual headphone outputs, each with independent volume control; dedicated headphone mix bus and separate headphone amp outputs
  • 4 Input Source Select switches with LED's
  • Mute, Dim and Mono monitoring switches with LED's
  • Built-in omnidirectional condenser talkback mic
  • Talkback control section with separate level control and individual 2-track and headphone or studio routing selector switches
  • Phono preamp with trim control for direct connection to turntables
  • Dedicated DAW mix input with trim control
  • Trim controls for all Source input connector sections
  • Stereo Studio Outs with dedicated switch and volume control, separate trim control for Studio Out connector section
  • Balanced or unbalanced +4/-10 operation for all connectors; balanced/unbalanced selector switches for 2-Track A and B, DAW Mix and DAW Phones Mix input sections, 2-Track A and B, DAW Output, and Phones Amp output sections
  • Dual Voltage power supply

Specifications

Frequency Response
Line-Level Inputs and Outputs 0+, -1 dB, 10 Hz-50 kHz
0+, -3dB, 5Hz-100kHz
RIAA Equalization Deviation (Phono Input) ± 0.5 dB, 20 Hz-20 kHz
Distortion
Line-Level Inputs to Line-Level Outputs (unity gain) >0.015%, 20 Hz-20 kHz @ +4 dBu
RIAA Input, Nominal Gain >0.015%, 20 Hz-20 kHz @ +4 dBu
Dynamic Range
Line Inputs 112 dB minimum
Phono Input 93 dB minimum
Dimensions (H x W x D) 3.2" (81 mm) x 13.5" (343 mm) x 5.9" (150 mm)
Weight 3.5 lbs (1.6 kg)
