The GEO M1012 is a compact, high-output touring line array speaker designed for precise sound control in professional live sound applications. Featuring a 10-inch 2-way passive design with 12° vertical coverage, it delivers focused projection and exceptional intelligibility, making it ideal for longer-throw arrays and venues where tight vertical pattern control is essential. Finished in touring-grade black, the GEO M1012 blends seamlessly into professional stage and rigging environments.
Built around advanced NEXO technologies, the GEO M1012 incorporates the patented Hyperbolic Reflective Wavesource (HRW) for the high frequencies and Phase Directivity Device (PDD) for the low frequencies, ensuring consistent tonal balance and smooth coverage across the entire listening area. The enclosure construction is derived from NEXO's flagship STM Series, using a durable honeycomb structure and optimized bass port design to deliver high output with low distortion in a compact form factor.
Designed for fast deployment on the road, the touring version features an integrated AutoRig system with no loose parts, allowing quick and secure flying or ground stacking. Horizontal coverage is 80° as standard and can be expanded to 120° using the optional patented CDD waveguide. Fully compatible with NEXO NXAMP powered controllers and NS-1 prediction software, the GEO M1012 offers predictable performance, easy system integration, and reliable results for demanding touring productions.
| Frequency Response @-6 dB | 59 Hz to 20 kHz |
|---|---|
| Sensitivity 1W@1m | 100 dB SPL Nominal |
| Peak SPL @1m | 136 dB |
| Vertical Dispersion | 12° |
| Horizontal Dispersion | 80° (without CDD), 120° (with CDD) |
| Passive Crossover Frequency | 1.3 kHz |
| Nominal Impedance | 8 Ohms |
| Recommended Power | 750 Watts |
| LF Component | 1 x 10" 8 Ohms long excursion Neodymium driver with PDD |
| HF Component | 1 x 1.4" throat driver on a BEA/FEA optimized HR Wavesource |
| Connectors | 2 x NL4, 4 poles connectors (1+/1- Through, 2+/2- GEO M10) |
| Construction | Lightweight Polyurethane Composite |
| Front Finish | Steel front grill + back mesh |
| Color | Black |
| Operating Temperature Range | 0°C - 40°C (32°F - 104°F) |
| Storage Temperature Range | -20°C - 60°C (-4°F - 140°F) |
| Dimensions (H x W x D) | 11.3" (288 mm) x 20.9 (531 mm) x 14" (355 mm) |
| Weight | 47 lbs (21 kg) |
