The GEO M1025 is a high-technology, compact touring line array speaker designed for mid-size professional sound reinforcement applications. Built around a 10" neodymium LF driver and a 1.4" HF driver, this 2-way passive line array element delivers exceptional clarity, controlled directivity, and consistent performance when stacked or flown, with or without its companion MSUB15 subwoofer.
Despite its compact dimensions, the GEO M1025 incorporates advanced technologies derived from NEXO's flagship STM Series. The HF section uses patented Hyperbolic Reflective Wavesource (HRW) technology, while the LF benefits from the Phase Directivity Device (PDD) for improved pattern control. The enclosure features a lightweight honeycomb structure with urethane co-polymer material and an optimized V-shaped bass port for efficient low-frequency performance.
The touring version of the GEO M1025 is finished in durable black and features a magnetically fixed steel front grille with back mesh, along with fully integrated AutoRig hardware that eliminates loose parts and speeds up deployment. Offering 25° vertical dispersion and 80° horizontal coverage as standard, expandable to 120° with the optional Configurable Directivity Device (CDD), the GEO M1025 provides outstanding flexibility. Combined with NEXO's NS-1 simulation software and full phase compatibility across NEXO systems, it delivers precise coverage and reliable performance for professional touring applications.
| Frequency Response @-6 dB | 59 Hz to 20 kHz |
|---|---|
| Sensitivity 1W@1m | 100 dB SPL Nominal |
| Peak SPL @1m | 136 dB |
| Vertical Dispersion | 25° |
| Horizontal Dispersion | 80° (without CDD), 120° (with CDD) |
| Passive Crossover Frequency | 1.3 kHz |
| Nominal Impedance | 8 Ohms |
| Recommended Power | 750 Watts |
| LF Component | 1 x 10" 8 Ohms long excursion Neodymium driver with PDDT |
| HF Component | 1 x 1.4" throat driver on a BEA/FEA optimized HR Wavesource |
| Connectors | 2 x NL4, 4 poles connectors (1+/1- Through, 2+/2- GEO M10) |
| Construction | Lightweight Polyurethane Composite |
| Front Finish | Steel front grill + back mesh |
| Color | Black |
| Operating Temperature Range | 0°C - 40°C (32°F - 104°F) |
| Storage Temperature Range | -20°C - 60°C (-4°F - 140°F) |
| Dimensions (H x W x D) | 11.3" (288 mm) x 20.9 (531 mm) x 14" (355 mm) |
| Weight | 47 lbs (21 kg) |
