Octasound SP860A 18" 360° x 180° Central Speaker System

Name: Octasound SP860A 18" 360° x 180° Central Speaker System
Brand: Octasound
SKU: OCTA-SP860A
Price: 3510 USD
Availability: InStock

Write a Review

Part #:

SP860A

Model #:

SP860A

Current Stock:

Availability: 90 Day Lead Time

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Octasound SP860A 18" central speaker system has a tuned port enclosure that contains a highly efficient 18" woofer matched to four compression horns and drivers. The frequency spectrum of the woofer and horns is determined by an internal crossover network that is optimized to maximize performance.

Description

Octasound SP860A 18-inch Omnidirectional Central Speaker System

The SP860A 18" central speaker system has a tuned port enclosure that contains a highly efficient 18" woofer matched to four compression horns and drivers. The frequency spectrum of the woofer and horns is determined by an internal crossover network that is optimized to maximize performance. This combination ensures full fidelity reproduction from an extremely compact central speaker system.

The KDM SP860A can withstand input power of 350 watts RMS. The KDM SP860A also contains a built-in, self-resetting thermal protective circuit. This protects the high frequency drivers from excessive and distorted (10% T.H.D.) input levels.

The KDM SP860A is extremely sensitive with a Sound Pressure Level (S.P.L.) of 104 dB per watt at 1 meter, hence very little amplifier power is required to obtain the required sound pressure levels. At maximum RMS input power the KDM SP860A can produce 128 dB S.P.L. at one meter.

Features

Up to 35,000 Square Feet sound coverage
Impact Resistant Rugged Polyurethane Elastomer Finish
Pucks, Basketballs, Lacrosse Balls, Projectiles - No Problem!
4 Suspension Points - Ready to Hang right out of the box
High Humidty Moisture Resistant Low Temperature Design
Long Lasting Performance and extremely durable components
4 High Compression Horn Drivers, 1 Sub-Woofer 18"
Manufactured in North America using Eminence components

Specifications

Frequency Response	20 Hz to 20 kHz ± 10 dB (on axis)
Optimum Power	100 to 300 watts RMS total
Power Handling	350 watts RMS total, 700 watts peak
Impedance	8 ohms nominal
Dispersion	360º Horizontal, 180º Vertical
Sensitivity	128 dB RMS / 131 dB Peak at 1 meter
Temperature Range	20ºC to 55ºC (-4ºF to 131ºF)
Humidity Range	0% to 100% Non Condensing
Weight	110 lbs
Material	Moisture Resisant Wood Composite Panel
Mounting Hardware	Four 11⁄2" Eye Nuts, 3⁄4" I.D. Eye 1⁄4 x 20 Thread
Shipping Weight	145 lbs
Shipping Dimension	40” (101.6cm) Square, by 24” (61cm) high
Coverage	360° x 180°— 35,000 sq ft (140 x 250 ft.)
Woofer / Midrange	18", 120 oz. Magnets, 4" Voice Coil
Horns (4)	9½" x 7¾" Glass Filled ABS
Drivers (4)	Exponential Compression, 24 Oz Magnets, 3" Voice Coils
Shipping Dimension	24” (610 mm) x 40” (1016 mm) x 40” (1016 mm)
Weight	110 lbs (50 kg)
Shipping Weight	145 lbs (65.8 kg)
