Peavey 6505 MH 20W Tube Guitar Amplifier

Peavey 6505 MH 20W Tube Guitar Amplifier

Name: Peavey 6505 MH 20W Tube Guitar Amplifier
Brand: Peavey
SKU: PEAVEY-03614180
Price: 899.99 USD
Availability: InStock

Write a Review

Part #:

03614180

Model #:

6505 MH

Current Stock:

MSRP: $1,299.99

$899.99

Availability: Usually arrives in 5-9 business days.

Quantity:

Adding to cart… The item has been added

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Featuring an all tube preamp and power amp, the 6505® MH authentically produces the much loved tones of the legendary Peavey 6505 in a small, portable package.

Description

Featuring an all tube preamp and power amp, the 6505® MH authentically produces the much loved tones of the legendary Peavey 6505 in a small, portable package.

The 6505® MH has two channels that follow the same gain structure and voicing of its big brother! The channels share EQ, lush reverb and an effects loop. Channels, crunch, effects loop and reverb are all footswitchable.

T.S.I.™ tube monitoring constantly lets you know that your power tubes are in good shape, and if not, which ones need to be replaced.

The back panel of the 6505 MH is full of modern technology, including Peavey's exclusive MSDI output, USB recording output, headphone output, speaker defeat switch, plus a built-in power attenuator!

Features

2x EL84 power tubes and 3x12AX7/ECC83 preamp tubes
Two footswitchable channels with 3-band EQ
Footswitchable crunch on Rhythm channel
Footswitchable reverb
Footswitchable buffered effects loop
Tube Status indication (T.S.I.™) circuit
MSDI™ Output with XLR and ground lift switch
USB output
Speaker defeat switch
Headphone output
Attenuator switch for 20 watts, 5 watts, or 1 watt output power
Footswitch included
Impedance switch for 16 or 8ohm cabinets

Specifications

General
Rated Power	20 W(rms) into 8 or 16Ω
Power Consumption (Domestic)	90 W, 50/60 Hz, 120 VAC
Tube Complement	2 x EL84, 3 x 12AX7/ECC83
Preamp Input Impedance	Very High-Z, 1MΩ
USB Output Level	Dependent on controls but -6dB (+/-3dB) at full power
Equalization	Custom Low, Mid, & High passive EQ
Effects Send
Low Impedance	To High-Z, 22kΩ or greater
Nominal Output Level	0 dBV, 1.0 V(rms)
Effects Return
Impedance	High-Z, 100kΩ
Physical
Dimensions (H x W x D)	7.25" (185 mm) x 14.00" (356 mm) x 7.75" (197 mm)
Weight	17 lbs (8 kg)
